Vishay 3-Element Uni-Directional TVS Diode 63 W, 7-Pin LLP1713 VBUS052CD-FAH-GS08
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Model | VBUS052CD-FAH-GS08 |
| Mount Type | Surface |
| Series | VBUS |
| Maximum Operating Temperature | 125°C |
| Package Type | LLP1713 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 7 |
| Number of Elements per Chip | 3 |
| Clamping Voltage VC | 12V |
| Diode Configuration | Triple |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 6.9V |
| Maximum Reverse Stand-off Voltage Vwm | 5V |
| Peak Pulse Power Dissipation Pppm | 63W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 3.5A |
| Maximum Reverse Leakage Current | 100nA |
| ESD immunity acc. IEC 61000-4-2 | ±15kV contact discharge and ±15kV air discharge |
Key Features
- Triple diode configuration provides effective transient voltage suppression.
- Uni-directional design suitable for high-speed data line protection.
- Surface mount package with low profile less than 0.6 mm height.
- Operating temperature range from -40°C to 125°C supports harsh environments.
- Low load capacitance of 0.8 pF minimizes circuit interference.
- ESD protection capability according to IEC 61000-4-2 with ±15 kV contact and air discharge.
- Maximum peak pulse current of 3.5 A for robust surge handling.
- Lead (Pb) free and halogen free environmentally compliant component.
Product Description
Vishay VBUS052CD-FAH-GS08 is a 3-element uni-directional TVS diode designed for transient voltage suppression in sensitive electronic circuits.
Housed in a compact 7-pin LLP1713 surface mount package with a height less than 0.6 mm, this diode offers superior ESD protection and low capacitance, making it ideal for high-speed data line applications.
The diode features a triple configuration for enhanced protection capability with a minimum breakdown voltage of 6.9 V and a maximum reverse stand-off voltage of 5 V, ensuring operational reliability under high-voltage transients.
Its peak pulse power dissipation rating of 63 W and maximum peak pulse current of 3.5 A make it suitable for demanding surge suppression tasks, while the clamping voltage at 12 V safeguards connected components.
The device operates effectively over a wide temperature range from -40°C to 125°C, proving its robustness in industrial, commercial, and automotive environments. Environmental compliance includes halogen-free and lead-free construction, making it suitable for green manufacturing practices.
Triple diode configuration provides effective transient voltage suppression. Uni-directional device supports ESD protection up to ±15 kV contact discharge. Low load capacitance ensures minimal signal distortion in sensitive circuits.
Compact surface-mount LLP1713 package enables space-saving PCB layouts. Wide operating temperature range from -40°C to 125°C for varied applications. Peak pulse power dissipation of 63 W supports high surge events. Maximum reverse leakage current is 100 nA, preserving circuit performance.
Lead-free and halogen-free for environmentally friendly compliance. Certified according to IEC 61000-4-2, IEC 61000-4-5, J-STD-020, and UL 94 V-0 standards. Ideal for protecting sensitive electronics, high-speed data lines, and industrial equipment.
This Vishay TVS diode VBUS052CD-FAH-GS08 is widely used in industrial electronics, telecommunications, automotive circuits, and other commercial applications for reliable ESD and transient voltage protection.
Explore our comprehensive range of Semiconductors and TVS diodes on EnvMart for robust circuit protection solutions from trusted brands like Vishay.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation rating of this model is 63 W, making it suitable for high surge events.
This diode operates effectively over a wide temperature range from -40°C to 125°C.
The clamping voltage for this unit is 12 V, which helps safeguard connected components during transient events.
This diode features a triple configuration, with 3 elements per chip for enhanced protection capability.
The maximum peak pulse current for this diode is 3.5 A, allowing it to handle robust surge conditions.
It is housed in a compact 7-pin LLP1713 surface mount package with a height of less than 0.6 mm.
This diode provides ESD protection according to IEC 61000-4-2, with ±15 kV contact and air discharge ratings.
The load capacitance is 0.8 pF, which minimizes circuit interference in sensitive applications.
Yes, it is lead-free and halogen-free, making it compliant with environmentally friendly manufacturing practices.
It is widely used in industrial electronics, telecommunications, automotive circuits, and other commercial applications for reliable ESD and transient voltage protection.
The minimum breakdown voltage is 6.9 V, ensuring effective transient voltage suppression.
