STMicroelectronics Surface Mount Schottky Diode 60 V 1 A 2-Pin DO-214AC STPS160A

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics Surface Mount Schottky Diode 60 V 1 A 2-Pin DO-214AC STPS160A

Name: STMicroelectronics Surface Mount Schottky Diode 60 V 1 A 2-Pin DO-214AC STPS160A
Brand: STMicroelectronics
SKU: 116468



Category Semiconductors Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	2.45mm
Length	4.6mm
Model	STPS160A
Width	2.9mm
Mount Type	Surface
Series	STPS160
Maximum Operating Temperature	150°C
Package Type	DO-214AC
Minimum Operating Temperature	-65°C
Pin Count	2
Maximum Continuous Forward Current If	1A
Peak Reverse Repetitive Voltage Vrrm	60V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	4μA
Peak Non-Repetitive Forward Surge Current Ifsm	75A
Maximum Forward Voltage Vf	0.49V

Key Features

The diode features a low forward voltage of 0.49 V for efficient power management.
Designed for surface mount applications with a 2-pin configuration.
Operates reliably across a temperature range from -65°C to 150°C.
Supports a peak non-repetitive forward surge current of 75 A.
Offers high switching speed with a maximum forward current of 1 A.
The package dimensions are 4.6 mm length, 2.9 mm width, and 2.45 mm height.
Peak reverse current is low at 4 μA, reducing leakage losses.
Suitable for high density and high power efficiency circuits.

Product Description

STMicroelectronics STPS160A is a Schottky barrier diode designed for surface mount technology in a DO-214AC package. This discrete semiconductor diode supports a maximum continuous forward current of 1 A and a peak reverse repetitive voltage of 60 V, making it suitable for low voltage, high frequency power applications.

The device has a maximum forward voltage drop of 0.49 V, contributing to efficient power conversion and reduced heat dissipation. It features a fast switching capability with a peak non-repetitive surge current of 75 A, which supports transient load handling.

The diode operates safely over a wide temperature range from -65°C to 150°C allowing usage in demanding environments such as automotive power circuits and industrial machinery. It has a low peak reverse current of 4 μA minimizing leakage currents.

With compact physical dimensions of 4.6 mm length, 2.9 mm width, and 2.45 mm height, the STPS160A is suitable for applications requiring high power density such as power supplies, rectifiers, and DC-DC converters.

The 2-pin surface mount configuration facilitates integration on printed circuit boards, enhancing manufacturing efficiency. Although it does not have automotive standard certification, it is widely used in industrial and electronic component assemblies.

The diode supports applications in power management, industrial electronics, and embedded systems requiring reliable and efficient rectification of AC to DC signals. The diode features a low forward voltage of 0.49 V for efficient power management.

Designed for surface mount applications with a 2-pin configuration. Operates reliably across a temperature range from -65°C to 150°C. Supports a peak non-repetitive forward surge current of 75 A. Offers high switching speed with a maximum forward current of 1 A.

The package dimensions are 4.6 mm length, 2.9 mm width, and 2.45 mm height. Peak reverse current is low at 4 μA, reducing leakage losses. Suitable for high density and high power efficiency circuits. Meets industrial requirements though it does not have specific automotive certification.

Ideal for use in power electronics, power supplies, automotive, and industrial applications. Explore more electronic components and Semiconductors at EnvMart for your industrial and manufacturing needs.
