onsemi CMOS Inverter 6 Elements, 14-Pin SOIC Package, 2.0-6.0 V Supply Voltage MC74HCU04ADG

Free Delivery in India | Lowest Global Shipping Charges

onsemi CMOS Inverter 6 Elements, 14-Pin SOIC Package, 2.0-6.0 V Supply Voltage MC74HCU04ADG

Name: onsemi CMOS Inverter 6 Elements, 14-Pin SOIC Package, 2.0-6.0 V Supply Voltage MC74HCU04ADG
Brand: onsemi
SKU: 374403
Price: 0.34 USD
Availability: InStock



Category Semiconductors Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	8.75mm
Model	MC74HCU04ADG
Width	4mm
Mount Type	Surface
Output type	LSTTL
Series	MC74HCU04A
Input Type	CMOS
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-55°C
Pin Count	14
Number of Elements per Chip	6
Automotive Standard	AEC-Q100
Maximum Supply Voltage	6V
Logic Family	LS
Logic Function	Inverter
Minimum Supply Voltage	2V
Maximum High Level Output Current	-5.2mA
Maximum Propagation Delay Time @ CL	105ns
Maximum Low Level Output Current	5.2mA
Supply voltage Vcc range	2.0 to 6.0V

Key Features

This inverter IC belongs to the 74HCU04A series and employs high-speed CMOS technology.
It has a maximum propagation delay time of 105 ns at capacitive load and outputs low-level and high-level currents up to 5.2 mA.
The device provides latch-up protection exceeding JESD 22 standards and operates reliably from -55°C to 125°C.
Its compact dimensions include a length of 8.75 mm, width of 4 mm, and height of 1.5 mm.
The logic function is inverter with CMOS input and LSTTL-compatible output.
This component meets AEC-Q100 automotive standards and is designed for industrial and automotive semiconductor applications.

Product Description

onsemi MC74HCU04ADG is a CMOS inverter IC featuring six inverter elements contained in a compact 14-pin SOIC surface-mount package. It supports a wide supply voltage range from 2.0 V to 6.0 V, making it suitable for a variety of CMOS logic applications.

This high-speed CMOS device provides an effective solution for signal inversion in digital circuits, characterized by low power consumption and fast switching speeds with a typical propagation delay of 105 nanoseconds at a standard capacitive load.

Designed to deliver output currents of ±5.2 mA, the MC74HCU04ADG ensures robust performance and compatibility with LSTTL logic levels. It operates over a wide temperature range from -55°C to 125°C, supporting industrial temperature requirements and reliability.

Its build meets rigorous AEC-Q100 automotive standards, highlighting its suitability for use in automotive electronics systems demanding high quality and durability. The inverter does not include Schmitt trigger inputs, focusing on pure inversion logic functions.

The physical package measures 8.75 mm in length, 4 mm in width, and 1.5 mm in height, making it ideal for compact PCB assemblies in manufacturing, industrial automation, and electronic component design sectors. This device is also protected against electrostatic discharge beyond established industry test levels, ensuring longer operational life and resistance to external electrical disturbances.

This product is ideal for high-speed logic inversion applications in industrial, automotive, and consumer electronics. It supports PCB surface mounting techniques with a standard SOIC form factor, enabling efficient automated assembly.

Protected against ESD with a human body model exceeding 1000 V and machine model exceeding 200 V. This inverter IC enhances circuit stability and performance in complex digital systems. Explore more semiconductor solutions and industrial-grade logic ICs in EnvMart's comprehensive catalog to find components that match your exact technical requirements.

Explore more products in our Semiconductors category.
