Texas Instruments 6-Channel Inverting Open Drain Hex Buffer 14-Pin SOIC SN74HC05DR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 2mm |
| Length | 10.5mm |
| Model | SN74HC05DR |
| Mount Type | Surface |
| Output type | Open Drain |
| Series | SN74HC05 |
| Input Type | CMOS |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Polarity | Inverting |
| Number Of Channels | 6 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Maximum Supply Voltage | 6V |
| Logic Family | 74HC |
| Logic Function | Inverter |
| Minimum Supply Voltage | 2V |
| Maximum Propagation Delay Time @ CL | 160ns |
| Supply Current | 40μA |
Key Features
- This hex buffer includes six independent inverting channels for high-performance logic operations.
- It features a surface mount SOIC 14-pin package for efficient PCB integration.
- Wide operating voltage range from 2V to 6V supports versatile applications.
- Designed to operate safely from -40°C to 85°C operating temperature ensuring durability.
- Propagation delay time is a maximum of 160 nanoseconds for fast switching.
- Supply current is low at 40 microamperes, suitable for energy-efficient circuits.
- Output polarity is inverting with open drain type for external pull-up configurations.
- The product is RoHS compliant, assuring environmental safety in electronics manufacturing.
Product Description
Texas Instruments SN74HC05DR 6-Channel Inverting Open Drain Hex Buffer 14-Pin SOIC is designed to provide reliable and efficient logic inversion with CMOS technology input and open drain output. Operating within a supply voltage range of 2V to 6V, this hex buffer integrates six independent inverting channels that suit complex logic circuits and automation systems.
The device features a compact 14-pin SOIC surface mount package with a length of 10.5 mm and height of 2 mm, enabling easy surface mount soldering on printed circuit boards used in industrial, laboratory, and commercial electronic applications.
It functions effectively within a temperature range of -40°C up to 85°C, accommodating harsh environmental conditions commonly found in industrial and embedded electronics. With a maximum propagation delay of 160ns and a low supply current of 40μA, the buffer ensures efficient switching performance with minimal power consumption.
Other technical attributes include an inverting open drain output type with CMOS input, making it ideal for interfacing with various logic families and for systems requiring open drain outputs for wired-AND functions or level shifting.
This hex buffer contains six inverting open drain channels. It comes in a 14-pin SOIC package suitable for surface mount technology. Operational from a minimum supply voltage of 2V up to a maximum of 6V. The device ensures reliable operation across a wide temperature range of -40°C to 85°C.
Low power consumption with a supply current of 40μA supports energy-efficient electronics. The maximum propagation delay at capacitive load is 160 nanoseconds. Fully RoHS compliant, meeting current environmental standards.
Designed for industrial, laboratory, telecommunications, and embedded system applications requiring logic inversion. Easy integration into automated manufacturing and electronic development environments. Explore more electronic components and logic ICs from Texas Instruments and other leading manufacturers at EnvMart, your trusted source for quality semiconductor products.
Explore more products in our Semiconductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum supply voltage for this model is 6V.
It operates effectively within a temperature range of -40°C to 85°C.
This hex buffer includes six independent inverting channels.
The maximum propagation delay time is 160 nanoseconds.
It features an inverting open drain output type.
The supply current is low at 40 microamperes.
The device comes in a 14-pin SOIC surface mount package.
It utilizes a CMOS input type for its operation.
Yes, the SN74HC05DR is fully RoHS compliant, meeting current environmental standards.
The dimensions are 10.5 mm in length and 2 mm in height.
The logic family is 74HC, which is compatible with various logic families.
