Texas Instruments 1 2-Input AND Logic Gate, 5-Pin SC-70 SN74LVC1G08DCKR

Texas Instruments SN74LVC1G08DCKR is a 1 2-Input AND Logic Gate housed in a 5-Pin SC-70 surface mount package. This component is part of the 74LVC family of low-voltage CMOS logic ICs designed for efficient operation in modern electronic circuits requiring low power consumption and high speed.

The device supports a broad operating voltage range of 1.65 to 5.5 volts, making it suitable for various applications compatible with TTL and CMOS standards. It presents a maximum propagation delay time of just 5 nanoseconds, enabling high-speed logic operations in digital designs.

With one logic element featuring two inputs, it provides basic AND logic functionality critical in combinational circuits. The gate output is CMOS type with a maximum output current of ±32mA. Notably, this device does not include Schmitt trigger inputs and utilizes the LVC logic family for low power dissipation.

The compact SC-70 package measures 2.15mm in length and 1mm in height, optimized for surface mount technology in space-constrained PCB layouts. It operates reliably across a wide temperature range from -40°C to 125°C, suitable for industrial and commercial electronics.

This gate is manufactured in China, ensuring quality and consistency. The 74LVC family’s 5V tolerant inputs provide design flexibility, making this IC ideal for a variety of logic circuit designs in consumer electronics, communication devices, and industrial automation systems.

This logic gate has 1 element with 2 inputs per gate. The device operates with a supply voltage range of 1.65 to 5.5 volts. Logic family is LVC, compatible with TTL and CMOS input types. Maximum propagation delay time is 5 nanoseconds at typical load capacitance.

It features low power consumption and high noise tolerance with no Schmitt trigger input. Operating temperature range spans from -40°C to 125°C for reliable industrial use. The compact SC-70 surface mount package has 5 pins with length 2.15mm and height 1mm.

The output type is CMOS with maximum output current of ±32mA. Designed as part of the 74LVC family for 3.3V system compatibility with 5V tolerant inputs. Manufactured in China for quality assurance and robust performance.
