| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1mm |
| Length | 2.2mm |
| Model | 74AHCT1G00SE-7 |
| Mount Type | Surface |
| Output type | Totem Pole |
| Supply Voltage range | 4.5V to 5.5V |
| Input Type | CMOS |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-353 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 5 |
| Number of Elements | 1 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | AHCT |
| Logic Function | NAND |
| Minimum Supply Voltage | 4.5V |
| Maximum High Level Output Current | -8mA |
| Maximum Propagation Delay Time @ CL | 10ns |
| Maximum Low Level Output Current | 8mA |
| Number of Inputs per Gate | 2 |
DiodesZetex 74AHCT1G00SE-7 is a high-performance 1 2-Input NAND Logic Gate designed in a compact 5-pin SOT-353 surface-mount package. Part of the AHCT logic family, this device operates within a supply voltage range of 4.5V to 5.5V, making it suitable for TTL-compatible digital logic circuits.
It features a maximum propagation delay of 10ns at CL, supporting high-speed switching requirements. The gate contains a single logic element with two inputs, providing robust logic NAND functionality for complex logic circuits. The output stage employs a totem pole configuration, which facilitates fast switching and improved output drive capability.
Designed for reliability, this component supports a wide operating temperature range from -40°C up to 125°C, ensuring stable performance in demanding environments. The package dimensions include a height of 1mm and a length of 2.2mm, contributing to minimal PCB footprint and enabling high-density designs.
Additionally, the 74AHCT1G00SE-7 is equipped with superior ESD protection, exceeding JESD 22 standards for both machine model (200V) and human body model (2000V), safeguarding the device against electrostatic discharge events during handling and operation.
This logic gate finds extensive applications across industrial, laboratory, consumer electronics, telecommunications, and automotive electronic systems where precise digital logic functions are essential.
Operates at 4.5V to 5.5V supply voltage range compatible with TTL levels. Maximum propagation delay time is 10 nanoseconds. Single logic element with two inputs per gate. Totem pole output for improved drive capability. Compact 5-pin SOT-353 surface mount package.
Operating temperature range from -40°C to 125°C. Height 1mm and length 2.2mm package dimensions. ESD protection exceeding JESD 22 standards. Manufactured in China ensuring compliance with quality standards. Explore more high-quality semiconductor products within the Logic Gate category at EnvMart to fulfill your industrial and design requirements.
