Texas Instruments 1 2-Input AND Logic Gate, 5-Pin SC-70 SN74LVC1G08DCKR

Texas Instruments SN74LVC1G08DCKR is a highly reliable 1 2-input AND logic gate integrated circuit housed in a 5-pin SC-70 surface mount package. It belongs to the 74LVC family of low-voltage CMOS logic devices, which utilize advanced silicon gate CMOS technology to enable operation at lower power voltages, reducing overall power consumption compared to traditional 5V logic ICs.

This device supports voltage operation from a minimum of 1.65V up to 5.5V, making it suitable for a variety of logic level systems. The input is TTL and CMOS compatible while the output operates at LVCMOS levels, ensuring broad compatibility with modern digital circuitry.

The IC offers a single AND gate function with two inputs and is built to industrial operating temperature standards of -40°C to 125°C. Propagation delay is low, with a maximum of 5ns at standard loading, enabling high-speed logic operations. The device includes robust ESD protection exceeding JESD 22 and latch-up immunity surpassing JESD 17, which contributes to long-term reliability in industrial, laboratory, and manufacturing environments.

The compact SC-70 package with 5 pins supports surface mounting on PCBs, making it ideal for space-constrained electronic assemblies. The maximum output drive current is ±32mA, sufficient to drive most logic devices directly.

Wide operating voltage range of 1.65V to 5.5V allows flexibility in system design. High-speed propagation delay of 5ns for fast logic switching. Single 2-input AND gate with TTL and CMOS compatible inputs. Surface mount SC-70 package ensures compact PCB footprint.

Extended industrial temperature range from -40°C to 125°C. Robust ESD and latch-up protection compliant with industry standards. Compatible with LVTTL/TTL input and LVCMOS output levels. Low power consumption using 74LVC silicon gate CMOS technology.

This component is widely used in industrial automation, embedded systems, digital instrumentation, and electronic control systems requiring reliable, low-voltage logic gating functionalities. It is appropriate for laboratories, manufacturing setups, and electronic device assemblies requiring dependable logic ICs.
