Texas Instruments 1 2-Input NAND Logic Gate, 5-Pin SC-70 SN74LVC1G00DCKR

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments 1 2-Input NAND Logic Gate, 5-Pin SC-70 SN74LVC1G00DCKR

Name: Texas Instruments 1 2-Input NAND Logic Gate, 5-Pin SC-70 SN74LVC1G00DCKR
Brand: Texas Instruments
SKU: 132075
Price: 0.08 USD
Availability: InStock



Category Logic Gate Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	1mm
Operating Voltage Range	1.65 to 3.6V
Length	2.15mm
Model	SN74LVC1G00DCKR
Mount Type	Surface
Compatibility	Input LVTTL/TTL, Output LVCMOS
Output type	CMOS
Series	SN74
Input Type	CMOS, TTL
Maximum Operating Temperature	125°C
Package Type	SC-70
Minimum Operating Temperature	-40°C
Pin Count	5
Number of Elements	1
Maximum Supply Voltage	5.5V
Logic Family	LVC
Logic Function	NAND
Minimum Supply Voltage	1.65V
Maximum High Level Output Current	-32mA
Maximum Propagation Delay Time @ CL	4.3ns
Maximum Low Level Output Current	32mA
Number of Inputs per Gate	2
Texas Instruments SN74LVC1G00DCKT 2-Input NAND Logic Gate, 5-Pin SC-70Brand	Texas Instruments

Key Features

This logic gate has a CMOS output type suitable for low power applications.
It operates within a supply voltage range of 1.65V to 5.5V, allowing compatibility with various systems.
Maximum propagation delay time at CL is 4.3 nanoseconds, providing fast switching performance.
Component supports operation between -40°C and +125°C for robust industrial use.
It integrates a 2-input NAND logic function with a single element per gate.
The device is surface mount type, designed for space-efficient PCB layouts.
Input compatibility includes CMOS and TTL logic types, ensuring broad interoperability.
Pin count is 5 with a compact SC-70 package measuring 2.15mm x 1mm.

Product Description

Texas Instruments SN74LVC1G00DCKR is a high-performance 1 2-Input NAND Logic Gate housed in a compact 5-pin SC-70 surface mount package. Operating over a wide voltage range from 1.65V to 5.5V, this device uses low-voltage CMOS technology to minimize power consumption while ensuring compatibility with LVTTL/TTL input logic levels and LVCMOS outputs.

Designed for robust industrial and commercial electronics applications, this logic gate offers a fast maximum propagation delay of 4.3 nanoseconds at typical load capacitance. It functions reliably within ambient temperatures ranging from -40°C to 125°C, suitable for harsh environmental conditions.

With a single 2-input NAND gate element, the SN74LVC1G00DCKR is ideal for use in digital logic circuits requiring NAND functionality, including signal processing, control units, and timing logic blocks. The 5-pin SC-70 package facilitates compact PCB layouts and surface mount assembly, reducing overall board space and improving manufacturing efficiency.

Key technical features include CMOS output type, 5V tolerant inputs for flexible interfacing, and compatibility with both CMOS and TTL input types. The small 2.15mm length by 1mm height package dimensions ensure ease of integration in dense electronic assemblies.

This device is suitable for industrial, commercial, and electronic manufacturing applications. Standard operating voltage from 1.65V up to 5.5V supports diverse power supply environments. The input logic supports CMOS and TTL, increasing interface flexibility.

Robust thermal tolerance and fast propagation times enable reliable performance under varying operating conditions. The 5-pin SC-70 surface mount design allows for space-saving PCB layouts. Ideal for integration into logic circuits, signal gating, and digital processing applications.

Choose Texas Instruments SN74LVC1G00DCKR for efficient Logic Gate performance with compact design and industrial-grade reliability. Explore similar high-quality semiconductor and logic ICs in the EnvMart catalog for your electronic component needs.
