Texas Instruments 4 2-Input NAND Logic Gate with 14-Pin PDIP Package SN74LS38N

Texas Instruments SN74LS38N is a 4 two-input NAND logic gate integrated circuit housed in a 14-pin PDIP package designed for through-hole mounting. Operating under a supply voltage range of 4.75V to 5.25V, it delivers reliable digital logic functionality compatible with standard 74LS logic families. The device features an open collector output type and provides a maximum propagation delay of 10ns at specified load capacitance. It operates efficiently at temperatures between 0°C and 70°C.

Manufactured using bipolar junction technology combined with Schottky diode clamps, the SN74LS38N achieves speeds comparable to the original 74TTL family while consuming less power, ideal for electronic components and semiconductor applications.

Typical industrial, laboratory, and manufacturing uses include digital logic circuits, control systems, signal processing, embedded systems, and electronic prototyping. Its robustness and compatibility make it suitable for various instrumentation and automation equipment requiring low-power high-speed logic gating.

Key features:. Contains 4 independent two-input NAND logic gates per IC. Standard 14-pin PDIP package for easy integration in printed circuit boards. Open collector output allows wired-AND operations in digital designs. Operating voltage supports a nominal 5V logic level common in control systems.

Temperature rating ensures stability and performance in typical industrial environments. Compatibility with 74LS logic family facilitates mixed-logic designs. Offers low power consumption relative to older 74TTL devices.

Suitable for educational, research, and automated industrial product development. This product is available as new and is a widely used standard logic gate IC from Texas Instruments, ensuring quality and reliability in complex electronic circuits.

Explore more semiconductor and Logic Gate components to build efficient digital systems at EnvMart.
