Texas Instruments 4 2-Input OR Schmitt Trigger Input Logic Gate, 14-Pin SOIC SN74HC7032D

Texas Instruments SN74HC7032D is a 4 2-Input OR Schmitt Trigger Input Logic Gate designed for high-speed digital logic applications. Packaged in a 14-Pin SOIC surface mount form, this logic IC operates efficiently within a 2 to 6 V voltage range suitable for a variety of electronic and semiconductor uses.

Utilizing silicon gate CMOS technology, the SN74HC7032D combines the speed of LSTTL logic with the low power consumption benefits inherent to CMOS devices. This IC integrates four independent gates, each with two inputs featuring Schmitt trigger characteristics to improve input signal noise immunity and switching precision.

The device has a maximum propagation delay of 28 nanoseconds, allowing for rapid logic signal processing in complex circuits. It supports operation in challenging environmental conditions with a minimum operating temperature of -40°C and maximum of 85°C.

The 14-pin SOIC package promotes ease of installation on surface mount PCBs, fitting well in compact designs. Outputs are push-pull type, compatible with CMOS voltage levels, making this IC suitable for contemporary digital systems including industrial, automotive (non-certified), and communications equipment.

Applications include logic signal conditioning, digital signal processing, and combinational logic design where fast response and noise immunity are critical. This device finds broad use in semiconductor, electronics components manufacturing, and industrial electronics sectors.

Each IC contains four independent 2-input OR gates with Schmitt trigger inputs for signal conditioning. The device operates over a wide voltage range of 2 to 6 V with low power consumption. Maximum propagation delay time is 28 nanoseconds ensuring fast switching speeds.

Designed for surface mount applications with a standard SOIC 14-pin package. Operating temperature range is -40°C to 85°C for industrial-grade reliability. Outputs feature push-pull type providing compatible CMOS logic levels.

The logic family is part of the HC series employing silicon gate CMOS technology. Compatible with both CMOS input and output logic levels for flexible system integration. Explore more advanced semiconductor and logic IC solutions in the Electronics & Electricals category at EnvMart.
