Texas Instruments 1 2-Input AND Schmitt Trigger Input Logic Gate Surface Mount 5-Pin SOT-23 SN74AHC1G08DBVR

Texas Instruments SN74AHC1G08DBVR is a single 2-input AND logic gate featuring Schmitt Trigger inputs, housed in a compact 5-pin SOT-23 surface mount package. It belongs to the 74AHC1G family of advanced high-speed CMOS logic devices, designed for high performance and low power dissipation in industrial and commercial electronic applications.

This device operates over a wide supply voltage range of 2 V to 5.5 V, making it suitable for modern low-voltage electronics. The Schmitt Trigger input enhances noise immunity and ensures stable logic levels, beneficial in environments with signal distortions or slow input transitions.

The maximum propagation delay time of 9.5 ns at typical load and conditions supports fast switching requirements, suitable for timing-critical digital circuits. Output drive capability is rated at ±8 mA at 5 V supply, enabling direct interfacing with various logic families and other electronic components.

Thermal and operational reliability is maintained with an extended temperature range from -40°C to 85°C, allowing use in harsh industrial and commercial environments. The device does not carry automotive qualification, making it primarily intended for general-purpose applications.

Operates at 2 - 5.5 V supply voltage. Schmitt Trigger input for enhanced noise immunity and signal stability. Compact 5-pin SOT-23 surface mount packaging. Maximum propagation delay of 9.5 ns at specified load. Low quiescent current of 10 μA maximizes energy efficiency.

Output drive of ±8 mA at 5 V supply. Operating temperature from -40°C to 85°C. No automotive or formal industrial approvals.

This Logic Gate is ideal for industrial automation, electronic instrumentation, communication equipment, and general digital circuit design where compact size and power efficiency are critical.
