DiodesZetex Silicon Junction Switching Diode, Single, 3 A, 200 V, Surface Mount SMC ES3D-13-F

DiodesZetex ES3D-13-F Silicon Junction Switching Diode is designed for high-performance electronic and power semiconductor applications, providing reliable switching capability with a maximum forward current of 3 A. The surface mount SMC package offers a compact footprint, making it ideal for modern PCB designs requiring space efficiency.

This diode features a maximum forward voltage of 900 mV, which minimizes power loss during conduction. It withstands peak non-repetitive forward surge currents up to 100 A, ensuring durability under transient loading. The peak reverse repetitive voltage rating of 200 V enables the diode to effectively block high-voltage reverse pulses, suitable for switching operations.

The device operates reliably across a wide temperature range from -55°C to 150°C, making it suitable for industrial, telecommunications, and automotive electronics where thermal reliability is critical. Its peak reverse recovery time of 25 ns supports high-speed switching applications, enhancing overall circuit efficiency.

The diode's compact SMC surface mount package measures 7.11 mm in length, 6.22 mm in width, and 2.3 mm in height, facilitating high-density PCB assembly. With 2 pins and a single diode configuration, it is straightforward to implement in various circuit designs, including rectification and switching.

Maximum forward voltage of 900 mV ensures efficient diode performance. Peak non-repetitive forward surge current rating of 100 A supports transient load handling. Maximum peak reverse repetitive voltage of 200 V suitable for switching applications.

Operating temperature ranges from -55°C up to 150°C for reliable performance in harsh environments. Compact dimensions of 7.11 mm length, 6.22 mm width, and 2.3 mm height allow space-saving PCB design. Peak reverse recovery time of 25 ns enables high speed switching.

2-pin, single diode surface mount device with SMC package type. Manufactured in China and designed for industrial and electronic component applications.

This diode is widely used in industrial electronics, power supplies, telecommunications, automotive electronics, and other applications requiring a compact, reliable switching diode. Quality construction and specifications ensure dependable operation within demanding environments. Browse EnvMart’s Semiconductors and Diodes categories for additional components and related products.
