Nexperia 2-Element Uni-Directional ESD Protection Diode 40W 3-Pin SOT-23 MMBZ27VAL,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 2-Element Uni-Directional ESD Protection Diode 40W 3-Pin SOT-23 MMBZ27VAL,215

Name: Nexperia 2-Element Uni-Directional ESD Protection Diode 40W 3-Pin SOT-23 MMBZ27VAL,215
Brand: Nexperia
SKU: 131794
Price: 0.07 USD
Availability: InStock



Category ESD Protection Diode Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.1mm
Length	3mm
Model	MMBZ27VAL,215
Width	1.4mm
Mount Type	Surface
Series	MMBZ
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-55°C
Pin Count	3
Number of Elements per Chip	2
Clamping Voltage VC	40V
Automotive Standard	AEC-Q101
Diode Configuration	Common Anode
Direction Type	Uni-Directional
Minimum Breakdown Voltage Vbr	25.65V
Maximum Reverse Stand-off Voltage Vwm	22V
Peak Pulse Power Dissipation Pppm	40W
Maximum Peak Pulse Current Ippm	1A
Maximum Reverse Leakage Current	5nA
onsemi 2-Element Uni-Directional TVS Diode, 40 W, 3-Pin SOT-23Brand	onsemi

Key Features

Features a common anode diode configuration for efficient uni-directional ESD protection.
Operates with a minimum breakdown voltage of 25.65 volts and a maximum reverse stand-off voltage of 22 volts.
Delivers a peak pulse power dissipation of 40 watts with a clamping voltage of 40 volts.
Designed to function safely from -55°C up to 150°C operating temperature.
Compact surface-mount SOT-23 package with dimensions approximately 3mm length, 1.4mm width, and 1.1mm height.
Incorporates 2 elements per chip with low maximum reverse leakage current of 5nA for reliable performance.
Meets automotive standard AEC-Q101 ensuring quality and reliability for automotive electronics.
Provides effective ESD protection with a maximum peak pulse current of 1 ampere.

Product Description

Nexperia MMBZ27VAL,215 is a 2-element uni-directional Electrostatic Discharge (ESD) protection diode designed to safeguard sensitive electronic circuits. It offers a robust 40 watt peak pulse power dissipation capability in a small and convenient 3-pin SOT-23 surface-mounted package, making it suitable for compact electronic assemblies.

This diode utilizes a common anode configuration to provide effective uni-directional ESD protection, ensuring that transient voltage spikes are clamped to safe levels. The device features a minimum breakdown voltage of 25.65 V, and a maximum reverse stand-off voltage of 22 V, with a clamping voltage rating of 40 V, protecting circuits from sudden surges.

Rated for operation in extreme temperature ranges from -55°C to 150°C, the MMBZ27VAL,215 maintains reliability in harsh environmental conditions, including automotive applications due to its AEC-Q101 certification. The device has a maximum reverse leakage current of just 5 nA, which aids in minimizing power loss and interference.

Compact physical dimensions of approximately 3mm length, 1.4mm width, and 1.1mm height make it ideal for high-density PCB layouts. The diode includes 2 elements per chip, enhancing surge protection capabilities.

Common applications for this diode include transient voltage suppression in power supplies, digital electronics, industrial controls, instrumentation, telecommunications, and automotive electronic circuits requiring stringent ESD protection.

Common anode diode configuration provides uni-directional ESD protection. Peak pulse power dissipation of 40W withstands significant transient surges. Wide operating temperature range from -55°C to 150°C for rugged environments.

Small 3-pin SOT-23 surface-mount package fits compact circuit designs. Very low reverse leakage current (5 nA) ensures efficiency. Automotive grade reliability with AEC-Q101 certification. Protects sensitive components in industrial, automotive, and consumer electronics.

This transistor array is ideal for electronic engineers and designers looking for reliable ESD protection diodes in small footprint packages. Browse the Electronics & Electricals > Semiconductor > ESD Protection Diode category on EnvMart for more options.
