Nexperia Uni-Directional ESD Protection Diode DFN2510D, 6V Breakdown, 7A Peak Pulse Current PESD4USB3U-TBS
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1mm |
| Length | 2.5mm |
| Model | PESD4USB3U-TBS |
| Width | 0.78mm |
| Mount Type | Surface |
| Series | PESD4USB3U-TBS |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN2510D |
| Minimum Operating Temperature | -65°C |
| Interfaces | USB 2 |
| Standards/Approvals | IEC 61000-4-2 |
| Clamping Voltage VC | 3.5V |
| Automotive Standard | AEC-Q101 |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 6V |
| Maximum Reverse Stand-off Voltage Vwm | 3.3V |
| Maximum Peak Pulse Current Ippm | 7A |
| Maximum Reverse Leakage Current | 100nA |
| Infotainment applications | USB 2.0, SuperSpeed USB 3.2 at 10 Gbps, HDMI 2.0, HDBaseT |
Key Features
- Designed for USB 2.0 and SuperSpeed USB 3.2 interfaces up to 10 Gbps.
- Compact DFN2510D surface mount package with dimensions 2.5 mm x 0.78 mm x 1 mm.
- Minimum breakdown voltage of 6 V with maximum reverse stand-off voltage of 3.3 V.
- High peak pulse current rating of 7 A with low clamping voltage of 3.5 V.
- Wide operating temperature range from -65°C to 150°C, suitable for automotive applications.
- Complies with AEC-Q101 automotive standard and IEC 61000-4-2 ESD standards.
- Extremely low line capacitance of 0.5 pF per channel for minimal signal distortion.
- Matched 0.5 mm trace spacing and side-wettable flanks for automated optical inspection compatibility.
Product Description
The Nexperia PESD4USB3U-TBS is a uni-directional Electrostatic Discharge (ESD) protection diode designed primarily for safeguarding sensitive high-speed data interfaces including USB 2.0 and SuperSpeed USB 3.2 up to 10 Gbps, HDMI 2.0, DisplayPort, external Serial ATA (eSATA), Low Voltage Differential Signalling (LVDS), and Gigabit Multimedia Serial Link (GMSL) Serializer/Deserializer (SerDes) applications.
Housed in a compact DFN2510D surface mount package measuring 2.5 mm in length, 0.78 mm in width, and 1 mm in height, this diode provides excellent protection while maintaining minimal signal interference thanks to its ultra-low line capacitance of only 0.5 pF per channel.
Featuring a minimum breakdown voltage of 6 V and a maximum reverse stand-off voltage of 3.3 V, it supports peak pulse currents up to 7 A with a clamping voltage of 3.5 V, ensuring deep snap-back characteristics combined with a dynamic resistance of 0.4 Ohms for exceptional system-level ESD protection.
The device is rated for operation across a broad temperature range from -65°C to 150°C and meets the stringent automotive-grade standard AEC-Q101, making it suitable for use in automotive infotainment systems, A/V monitors, displays, and cameras.
Its design incorporates matched 0.5 mm trace spacing and side-wettable flanks for reliable automated optical inspection. This product is compliant with IEC 61000-4-2 for ESD protection, making it ideal in industrial, automotive, consumer electronics, and communication interface applications where robust ESD protection is critical.
Designed for USB 2.0 and SuperSpeed USB 3.2 with 10 Gbps data rate protection. Compact DFN2510D surface-mount package with small footprint. Voltage rating includes 6 V minimum breakdown and 3.3 V maximum stand-off. High peak pulse current handling of 7 A and low clamping voltage of 3.5 V.
Wide operating temperature suitability, from -65°C to 150°C, meeting automotive qualification. Automotive AEC-Q101 qualification ensures reliability in harsh environments. Low 0.5 pF line capacitance minimizes signal distortion in high-frequency lines.
Matched 0.5 mm trace spacing and side-wettable flanks for manufacturing inspection compatibility. Ideal for protecting interfaces such as HDMI, DisplayPort, eSATA, LVDS, and GMSL SerDes. Explore more Nexperia semiconductor and ESD protection products at EnvMart for your electronic component needs.
Explore more products in our ESD Protection Diode category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The minimum breakdown voltage of the PESD4USB3U-TBS diode is 6 V.
It has a maximum peak pulse current rating of 7 A.
The DFN2510D package measures 2.5 mm in length, 0.78 mm in width, and 1 mm in height.
This model operates within a temperature range of -65°C to 150°C.
It complies with AEC-Q101 automotive standard and IEC 61000-4-2 ESD standards.
The clamping voltage for the PESD4USB3U-TBS is 3.5 V.
It is designed for USB 2.0, SuperSpeed USB 3.2, HDMI 2.0, and other high-speed data interfaces.
The line capacitance is extremely low at 0.5 pF per channel, minimizing signal distortion.
It supports surface mounting, specifically in a DFN2510D package.
Yes, it is suitable for automotive applications and meets the AEC-Q101 standard.
The maximum reverse stand-off voltage is 3.3 V.
The maximum reverse leakage current is 100 nA.
