Nexperia Non-Inverting 3 State Buffer Logic IC, Single Channel, 5-Pin SC-74, 1.65V to 5.5V Operating 74LVC1G125GV,125

Nexperia 74LVC1G125GV,125 Non-Inverting 3 State Buffer is a specialized single-channel logic IC designed for efficient buffering and signal driving applications. Encased in a compact 5-pin SC-74 surface-mount package, it supports a broad operating voltage range from 1.65 to 5.5 volts, making it adaptable to various low-voltage CMOS systems.

This buffer IC offers a non-inverting 3 state output feature, allowing it to drive signals with excellent control and isolation. It provides reliable performance within industrial temperature limits ranging from -40°C to 125°C, suitable for demanding environments.

The device delivers a maximum propagation delay time of 10.5 nanoseconds at typical load conditions, ensuring rapid signal transitions crucial for high-speed digital circuits. With a minimal supply current of only 4 microamperes, the component is optimized for low power consumption, extending battery life in portable designs.

Its electrical compatibility includes input LVTTL/TTL logic levels and output LVCMOS, facilitating seamless interfacing with various digital logic families. The device has a maximum high level output current rating of -32 milliamperes and a maximum low level output current of 32 milliamperes, enabling it to drive different loads effectively.

Intended for electronic, power connector, and semiconductor applications, the 74LVC1G125 is ideal for buffering, level shifting, and signal isolation tasks in digital circuits. It is suitable for industrial manufacturing, electronic assembly lines, and embedded system designs requiring compact buffer ICs.

Features non-inverting 3 state output suitable for buffer applications. Operates within a temperature range from -40°C to 125°C ensuring reliable performance. Maximum propagation delay time of 10.5ns at CL provides fast switching capabilities.

Low supply current of 4μA enables energy-efficient operation. Compatible with input LVTTL/TTL and output LVCMOS logic levels for versatile interfacing. Compact SC-74 surface-mount package with just 5 pins ensures small PCB footprint.

Maximum high level output current of -32mA and low level output current of 32mA supports diverse load driving requirements. Ideal for use in electronic, semiconductor, and logic IC applications. Robust design without automotive standard approvals, optimized for industrial and consumer electronics.

This Nexperia buffer IC is expressly designed for use in electronics manufacturing, industrial controls, and communication equipment where compact size and reliable signal buffering are critical. The device supports surface-mount technology workflows and enhances PCB design flexibility.
