onsemi 3 State Bus Buffer, 14-Pin SOIC MC74VHCT125ADR2G

onsemi MC74VHCT125ADR2G is a 3 State Bus Buffer from the 74VHCT125A series designed to provide reliable buffering functionality with a 14-pin SOIC surface mount package. This device belongs to the HCT logic family and operates over a wide supply voltage range from 2V to 5.5V. It enables efficient signal buffering with three-state output capability, ideal for bus-oriented applications.

The buffer features a maximum propagation delay time of 16ns, making it suitable for timing-critical synchronous circuits. It consumes a low supply current of 75mA, contributing to power-efficient designs. The operating temperature range spans from -55°C to 125°C, allowing deployment in harsh industrial and automotive environments.

With a maximum high level output current of -25mA and maximum low level output current of 25mA, this IC is capable of driving moderate load conditions. Its CMOS input type ensures compatibility with a wide range of logic signals, although it does not feature Schmitt Trigger inputs.

Physically, the MC74VHCT125ADR2G is housed in a compact SOIC package with 14 pins, sized at 8.75mm in length and 1.5mm in height, ensuring easy integration on printed circuit boards with surface mount technology.

This bus buffer complies with the automotive standard AEC-Q100, certifying its robustness and reliability for automotive and industrial applications where quality and longevity are critical.

This buffer provides a 3-state output enabling bus-oriented applications. Low supply current of 75mA enables efficient operation. Fast propagation delay timing at 16ns for precise control. Wide operating temperature range ensures durability.

Supports moderate high and low output currents of ±25mA. Compact 14-pin SOIC package for surface mounting. Automotive standard AEC-Q100 compliant for high reliability. CMOS input type compatible with various logic circuits.

This device is ideal for electronics manufacturing, automotive electronic systems, signal buffering, and timing-critical digital applications. For more components in the buffering and semiconductor category, explore the onsemi series or browse related products on EnvMart.
