Texas Instruments 4-Channel 3 State Quad Bus Buffer CMOS Logic IC SOIC 14-Pin SN74LVC125AD

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments 4-Channel 3 State Quad Bus Buffer CMOS Logic IC SOIC 14-Pin SN74LVC125AD

Name: Texas Instruments 4-Channel 3 State Quad Bus Buffer CMOS Logic IC SOIC 14-Pin SN74LVC125AD
Brand: Texas Instruments
SKU: 412900
Price: 1 USD
Availability: InStock



Category Buffers Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	2mm
Length	10.5mm
Model	SN74LVC125AD
Mount Type	Surface
Output type	3 State
Series	SN74LVC125A
Input Type	CMOS
Maximum Operating Temperature	150°C
Package Type	SOIC
Minimum Operating Temperature	-65°C
Number Of Channels	4
Standards/Approvals	RoHS
Pin Count	14
Maximum Supply Voltage	3.6V
Logic Family	74LVC
Logic Function	Buffer
Minimum Supply Voltage	1.65V
Maximum High Level Output Current	-24mA
Maximum Low Level Output Current	24mA

Key Features

Operates within a supply voltage range of 1.65V to 3.6V.
Incorporates four separate buffer channels for versatile signal buffering.
Provides a 3-state output function enhancing bus management and signal control.
Features a compact 14-pin SOIC surface mount package for PCB space efficiency.
Supports operating temperatures from -65°C to 150°C suitable for industrial environments.
Utilizes CMOS input technology ensuring low power consumption.
Complies with RoHS standards ensuring environmental safety and compliance.
Maximum high-level output current is -24mA and maximum low-level output current is 24mA.

Product Description

Texas Instruments SN74LVC125AD is a high-performance 4-channel 3 state quad bus buffer utilizing CMOS technology, designed to provide reliable signal buffering in electronic systems. Packaged in a compact 14-pin SOIC surface mount device, it supports a wide operating voltage range from 1.65V to 3.6V, making it suitable for versatile applications.

This device features four independent buffer channels, each capable of 3-state output functionality to manage signal flow efficiently in bus systems. The 3-state output allows multiple devices to share a common bus line without interference, enhancing system flexibility and control.

Operating across a broad temperature spectrum from -65°C to 150°C, the SN74LVC125AD is built to endure industrial and demanding electronic environments. Its CMOS input technology ensures low supply current and improved power efficiency.

Designed to meet RoHS environmental regulations, this logic IC supports engineers in creating compliant and sustainable designs. The device's maximum output currents (24mA low level, -24mA high level) enable it to drive loads effectively without compromising performance.

Applications span various fields including industrial control, semiconductor manufacturing, signal processing, and embedded systems. The SN74LVC125AD's compact SOIC package reduces board space requirements, making it well-suited for dense electronic assemblies and PCB layouts.

Operates within 1.65V to 3.6V supply voltage range for flexible power design. Contains 4 independent buffer channels to manage multiple signal paths. 3-state output improves bus contention and signal handling. Surface mount SOIC package ensures minimal PCB footprint.

Wide operating temperature range (-65°C to 150°C) for industrial use. CMOS input type supports low power consumption and high noise immunity. RoHS compliant for environmental safety and regulatory conformance. Maximum output currents of 24mA (low level) and -24mA (high level) enable robust driving capability.

For advanced semiconductor buffer applications, the Texas Instruments SN74LVC125AD offers trusted performance and compliance standards. Explore related buffer ICs and electronic components at EnvMart for comprehensive electronic design solutions.
