Nexperia Encoder Logic IC, 6-Pin SC-74 Package, 74LVC Family Multiplexer, 1.65-5.5 V Supply, 2 Inputs, Model 74LVC1G157GV,125

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Encoder Logic IC, 6-Pin SC-74 Package, 74LVC Family Multiplexer, 1.65-5.5 V Supply, 2 Inputs, Model 74LVC1G157GV,125

Name: Nexperia Encoder Logic IC, 6-Pin SC-74 Package, 74LVC Family Multiplexer, 1.65-5.5 V Supply, 2 Inputs, Model 74LVC1G157GV,125
Brand: Nexperia
SKU: 419946
Price: 0.11 USD
Availability: InStock



Category Encoder & Decoder ICs Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1mm
Length	3.1mm
Model	74LVC1G157GV,125
Mount Type	Surface
Compatibility	Input LVTTL/TTL, Output LVCMOS
Number of inputs	2
Series	74LVC
Maximum Operating Temperature	125°C
Package Type	SC-74
Minimum Operating Temperature	-40°C
Operating Voltage	1.65 to 5.5 V
Pin Count	6
Maximum Supply Voltage	5.5V
Logic Family	74LVC
Logic Function	Multiplexer
Minimum Supply Voltage	1.65V

Key Features

Operates at a supply voltage range of 1.65 V to 5.5 V for versatile electronic use.
Features 2 inputs configured as a multiplexer logic function for signal selection.
Compact surface mount device with a small 3.1 mm length and 1 mm height footprint.
Operable within a wide temperature range from -40°C to 125°C for industrial reliability.
Compatible inputs LVTTL/TTL and output LVCMOS logic levels for comprehensive system integration.
Part of the 74LVC Logic family suitable for modern digital circuits requiring low power consumption.
Single gate package minimizes board space for dense circuit designs.

Product Description

Nexperia 74LVC1G157GV,125 Encoder logic integrated circuit belongs to the 74LVC family featuring low-voltage CMOS technology. It operates as a multiplexer with 2 inputs, designed for use in electronic and semiconductor applications requiring compact, surface-mount components.

This IC is housed in a 6-pin SC-74 package, measuring 3.1 mm in length and 1 mm in height, ideal for space-constrained circuit boards. It supports a broad supply voltage range from 1.65 V to 5.5 V, enabling flexibility in various low voltage environments.

The device operates across an extended industrial temperature range of -40°C to 125°C, ensuring functionality in demanding conditions. It is compatible with input logic levels LVTTL/TTL and provides LVCMOS output, improving digital signal compatibility.

The 74LVC1G157GV,125 is a single gate device from the 74LVC logic family that offers efficient multiplexing functionality, commonly used in control, automation, and signal routing in embedded systems, industrial electronics, and instrumentation.

Operates on a voltage range from 1.65 V to 5.5 V. Surface mount SC-74 package with 6 pins for compact integration. Wide temperature rating from -40°C to 125°C for robustness. Compatible with LVTTL/TTL inputs and LVCMOS outputs for flexible interfacing.

Single gate multiplexer logic function from the 74LVC family. Small physical dimensions: 3.1 mm length and 1 mm height.

This encoder IC is suitable for use in industrial, electronic, automotive, and embedded systems requiring reliable multiplexer performance in a minimal form factor. Its low voltage operation and broad temperature tolerance make it fit for harsh and low-power applications.
