Nexperia Low-Voltage CMOS Logic Encoder Multiplexer 6-Pin SC-88 Package 74LVC1G157GW,125

Nexperia 74LVC1G157GW,125 is a low-voltage CMOS logic encoder IC featuring a multiplexer function with 2 inputs. Packaged in a compact 6-pin SC-88 surface mount type, it operates over a wide voltage range from 1.65 V to 5.5 V, making it suitable for various semiconductor applications.

This device’s operating temperature spans from -40°C to 125°C, catering to both commercial and industrial environments. Its small physical footprint with dimensions of 2.2mm length and 1mm height supports high-density PCB designs.

The encoder is compatible with input LVTTL/TTL signals, outputting LVCMOS logic levels. It belongs to the 74LVC family known for reliable low-voltage CMOS logic performance without automotive-grade certification.

Common applications include sensor encoding, digital signal multiplexing, and other electronic component circuitry where compact logic ICs are essential. Supports 2 input signals in a multiplexer logic function. Surface mount device suitable for compact PCB layouts.

Operating temperature range from -40°C to 125°C for industrial use. Compact package dimensions with length 2.2mm and height 1mm. Compatible with LVTTL and TTL input levels and provides LVCMOS output. Part of the 74LVC logic family ensuring reliable performance.

Designed without automotive standards compliance. Ideal for semiconductor and electronic component applications. This encoder IC is ideal for industrial, manufacturing, and electronic instrumentation sectors requiring reliable multiplexing at low voltages.
