DiodesZetex 1 A NPN 45 V 3-Pin SOT-89 Transistor BCX5416TA

DiodesZetex BCX5416TA is a general purpose NPN bipolar transistor designed for a variety of industrial and electronic applications. With a maximum DC collector current rating of 1 A and a collector emitter voltage rating of 45 V, this transistor delivers reliable switching and amplification performance. Its compact 3-pin SOT-89 surface mount package simplifies integration on printed circuit boards while maintaining space efficiency.

The transistor supports a maximum power dissipation of 1 watt and a maximum transition frequency of 150 MHz, making it suitable for high-frequency applications. Its operating temperature ranges from -55°C to 150°C, catering to demanding industrial and automotive environments. The device meets automotive standards AEC-Q101, AEC-Q100, and AEC-Q200, ensuring suitability in automotive electronics where robustness is critical.

Physical dimensions of 4.6 mm length, 4.25 mm width, and 1.6 mm height contribute to compact system designs. The device features a minimum DC current gain (hFE) of 25 and a maximum emitter base voltage of 5 V, ensuring stable electrical performance. The BCX5416TA transistor is manufactured in China with quality controls adhering to electronic component standards.

This transistor is ideally used in applications requiring precise switching, amplification, and power handling such as industrial controls, automotive systems, telecommunications, and power regulation circuits. Its surface mount packaging is suited for modern automated assembly processes, facilitating mass production environments.

Set includes one BCX5416TA transistor in a 3-pin SOT-89 package ready for surface mounting. Industrial users benefit from its robust specifications, automotive qualification, and reliability under varied temperature conditions.

Maximum DC collector current of 1 ampere for robust applications. Supports collector emitter voltage up to 45 volts for various electronic needs. Compact 3-pin SOT-89 surface mount package for easy PCB integration. High-frequency operation with a maximum transition frequency of 150 MHz.

Wide operating temperature range from -55°C to 150°C for industrial environments. Automotive qualified meeting standards AEC-Q101, AEC-Q100, and AEC-Q200. Low minimum current gain of 25 ensuring stable transistor switching.

Maximum power dissipation of 1 watt suitable for moderate power applications. Dimensions of 4.6 mm length, 4.25 mm width, and 1.6 mm height for space-efficient design. Manufactured in China ensuring consistent quality and supply.
