onsemi CMOS Logic Multiplexer/Demultiplexer 16-Pin SOIC, 3 Elements, 2 to 6 V MC74HC4053ADR2G

Free Delivery in India | Lowest Global Shipping Charges

onsemi CMOS Logic Multiplexer/Demultiplexer 16-Pin SOIC, 3 Elements, 2 to 6 V MC74HC4053ADR2G

Name: onsemi CMOS Logic Multiplexer/Demultiplexer 16-Pin SOIC, 3 Elements, 2 to 6 V MC74HC4053ADR2G
Brand: onsemi
SKU: 242411
Price: 0.38 USD
Availability: InStock



Category Multiplexer/Demultiplexer ICs Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	10mm
Model	MC74HC4053ADR2G
Width	4mm
Mount Type	Surface
Compatibility	Input CMOS, Output CMOS
Output type	LSTTL, CMOS
Configuration	Triple
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-55°C
Operating Voltage	2 to 6 V
Standards/Approvals	RoHS
Pin Count	16
Number of Elements per Chip	3
Automotive Standard	AEC-Q100
Maximum Supply Voltage	12V
Logic Family	CMOS
Minimum Supply Voltage	2V
Multiplexer/Demultiplexer	Multiplexer, Demultiplexer
Maximum On State Resistance	280Ω

Key Features

This device supports both multiplexer and demultiplexer functions.
It features low On State Resistance of 280 ohms ensuring efficient signal transmission.
The package offers surface mount technology compatibility in a compact 16-pin SOIC form factor.
Operating temperature ranges from -55°C to 125°C allowing usage in diverse environments.
Compatible with CMOS inputs and outputs to ensure seamless integration with digital circuits.
Certified RoHS and meets AEC-Q100 automotive standards for reliability and environmental safety.
The device dimensions include a 10mm length, 4mm width, and 1.5mm height.
Minimum supply voltage is 2V with a maximum supply voltage of 12V, suitable for various voltage domains.

Product Description

onsemi MC74HC4053ADR2G is a high-speed CMOS Logic Multiplexer/Demultiplexer integrated circuit providing three independent channels within a 16-pin SOIC package. The device operates efficiently within a voltage range of 2 to 6 volts, making it ideal for diverse electronic and semiconductor applications.

This multiplexer/demultiplexer IC is designed for surface mount technology, enabling compact PCB designs. Its low on-state resistance of 280 ohms ensures minimal signal loss and power dissipation during switching.

The device is capable of operating reliably at temperatures from -55°C up to 125°C, which suits widespread industrial, automotive, and commercial electronics environments. Its compatibility with CMOS technology on both input and output stages permits seamless integration into modern CMOS-based digital systems.

Key physical dimensions are 10mm length, 4mm width, and 1.5mm height, enabling flexible mounting on PCBs where space optimization is crucial. This product complies with RoHS standards and meets the stringent AEC-Q100 automotive standard specification, confirming its suitability for automotive electronics applications requiring high reliability.

This IC contains three separate multiplexer/demultiplexer elements in one package. Operates on a 2V to 6V supply voltage range with a max supply up to 12V. Supports both multiplexer and demultiplexer functions on each channel.

Surface mount package type SOIC improves PCB assembly efficiency. Low on-resistance of 280Ω for enhanced signal integrity. Wide operating temperature from -55°C to 125°C suitable for harsh conditions. RoHS compliant and automotive standard AEC-Q100 certified for environmental and quality assurance.

This product is widely applicable in electronics manufacturing, industrial instrumentation, automotive electronics, and digital circuit design, offering robust performance and durability. It supports applications requiring switching and routing of digital signals efficiently.
