Toshiba Multiplexer/Demultiplexer Dual 4:1 CMOS Logic IC, 16-Pin TSSOP Package TC4052BFT(N)

Free Delivery in India | Lowest Global Shipping Charges

Toshiba Multiplexer/Demultiplexer Dual 4:1 CMOS Logic IC, 16-Pin TSSOP Package TC4052BFT(N)

Name: Toshiba Multiplexer/Demultiplexer Dual 4:1 CMOS Logic IC, 16-Pin TSSOP Package TC4052BFT(N)
Brand: Toshiba
SKU: 344973
Price: 1.22 USD
Availability: InStock



Category Multiplexer/Demultiplexer ICs Brand Toshiba Condition New

Specifications

Country of Origin	Japan
Brand	Toshiba
Height	1mm
Length	5.4mm
Model	TC4052BFT(N)
Width	4.4mm
Mount Type	Surface
Output type	CMOS
Series	TC4052B
Configuration	Dual 4:1
Maximum Operating Temperature	85°C
Package Type	TSSOP
Minimum Operating Temperature	-40°C
Pin Count	16
Number of Elements per Chip	2
Maximum Supply Voltage	18V
Logic Family	CMOS
Minimum Supply Voltage	3V
Multiplexer/Demultiplexer	Demultiplexer, Multiplexer
Maximum On State Resistance	1.2kΩ
ConfigurationDual 4	1
Dual 4	1
Toshiba TC4052BFT(N) Multiplexer/Demultiplexer, 2 CMOS Dual 4	1, Demultiplexer, Multiplexer, 16-Pin TSSOP

Key Features

Designed using CMOS logic family for low power consumption.
Packaged in a 16-pin TSSOP surface mount package for compact PCB integration.
Operates within a voltage supply range of 3V to 18V.
Maximum on state resistance of 1.2kΩ ensures efficient signal switching.
Rated for operating temperatures from -40°C to 85°C, suitable for varied environments.
Produced in Japan ensuring high manufacturing standards.

Product Description

The Toshiba TC4052BFT(N) is a high-quality dual 4:1 multiplexer/demultiplexer logic IC built with CMOS technology, designed for efficient and reliable signal switching applications. Housed in a slim 16-pin TSSOP package, this device is ideal for surface mount technology, enabling compact and lightweight PCB designs.

This logic IC supports a wide supply voltage range from 3V to 18V allowing flexible integration in various electronic circuits. With two independent elements in one chip, it offers dual 4:1 multiplexing/demultiplexing, making it suitable for complex switching tasks in digital and analog signal processing.

The IC exhibits a maximum on-state resistance of 1.2kΩ, ensuring minimal signal loss and high fidelity in switching functions. It functions reliably over a broad temperature range from -40°C to 85°C, allowing usage in industrial, automotive electronics, telecommunications, and consumer electronics applications.

Its compact dimensions (length 5.4mm, width 4.4mm, height 1mm) support densely packed circuits while maintaining performance. Manufactured in Japan, the component guarantees precise quality and adherence to rigorous standards.

CMOS logic family ensures low power consumption and high noise immunity. Dual 4:1 switching configuration allows multiple signal routing options. Surface mount TSSOP 16-pin package supports compact design and automated assembly.

The device supports minimum and maximum supply voltages of 3V and 18V respectively. Maximum on resistance of 1.2kΩ facilitates efficient analog switching. Wide operating temperature range from -40°C to 85°C suits diverse industrial and commercial environments.

Compact physical size allows integration in space-constrained designs. High manufacturing quality from Japan ensures product reliability.

This multiplexer/demultiplexer IC is widely used in industrial automation, telecommunications equipment, instrumentation, and other electronic systems requiring accurate signal routing and switching. It is ideal for engineers seeking quality and compact multiplexing solutions.

Explore more semiconductor and logic IC solutions in the Electronics & Electrical category at EnvMart for your precise component needs.

Explore more products in our Multiplexer/Demultiplexer ICs category.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business
