Toshiba AC Input Photocoupler Surface Mount, 4-Pin SO Package, 50mA Input Current, Model TLP182(GB-TPL,E(T

Free Delivery in India | Lowest Global Shipping Charges

Toshiba AC Input Photocoupler Surface Mount, 4-Pin SO Package, 50mA Input Current, Model TLP182(GB-TPL,E(T

Name: Toshiba AC Input Photocoupler Surface Mount, 4-Pin SO Package, 50mA Input Current, Model TLP182(GB-TPL,E(T
Brand: Toshiba
SKU: 423586
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand Toshiba Condition New

Specifications

Country of Origin	India
Brand	Toshiba
Model	TLP182(GB-TPL,E(T
Mount Type	Surface
Series	TLP
Maximum Operating Temperature	125°C
Package Type	SO
Minimum Operating Temperature	-55°C
Maximum input current	50mA
Number Of Channels	1
Standards/Approvals	cUL, CSA, UL, RoHS, VDE
Maximum Forward Voltage	1.4V
Number of Pins	4
Input Current Type	AC
Maximum Current Transfer Ratio	6%
Minimum Current Transfer Ratio	0.5%

Key Features

Designed with two antiparallel infrared LEDs coupled to a phototransistor.
Surface mount type suitable for automated assembly processes.
Maximum forward voltage of 1.4V with AC input current up to 50mA.
Operating temperature range from -55°C to 125°C ensures durability in harsh environments.
Current transfer ratio between 0.5% minimum and 6% maximum for efficient signal transfer.
Isolation voltage rated at 3750Vrms for safe electrical separation.
Compliant with cUL, CSA, UL, RoHS, and VDE standards for quality and safety.
Non-automotive grade component primarily used in power supply and PLC applications.

Product Description

Toshiba TLP182(GB-TPL,E(T AC input photocoupler is a surface mount device in a 4-pin SO package, specifically engineered to provide optical isolation in electronic circuits.

This device integrates a phototransistor optically coupled to two antiparallel infrared LEDs, allowing it to operate effectively with AC input currents up to 50mA while maintaining a maximum forward voltage of 1.4V.

The photocoupler is optimized for use in switching power supplies and programmable logic controllers (PLCs), supporting industrial, commercial, and automation applications requiring reliable signal isolation.

Designed to operate in extreme temperature conditions ranging from -55°C to 125°C, it ensures stable performance and long-term reliability in various environments. The current transfer ratio ranges from a minimum of 0.5% to a maximum of 6%, providing efficient signal transmission across isolation barriers.

The isolation voltage of 3750Vrms provides robust protection to sensitive electronics by preventing unwanted electrical interference between input and output circuits. This product adheres to multiple safety and quality standards including cUL, CSA, UL, RoHS, and VDE, ensuring compliance and environmental responsibility.

Equipped with surface mounting technology for streamlined PCB assembly. Non-automotive standard device suitable for industrial and consumer electronic applications. Compact 4-pin SO package type offers space-saving design on circuitry.

The Toshiba TLP182 series photocoupler remains a trusted solution in the category of optocouplers, seamlessly integrating into systems requiring electrical isolation, signal integrity, and regulatory compliance.
