Vishay Multiplexer 4 Single 4:1, 12-Pin QFN Surface Mount, 1.8V to 5.5V Supply DG2034EDN-T1-GE4

Free Delivery in India | Lowest Global Shipping Charges

Vishay Multiplexer 4 Single 4:1, 12-Pin QFN Surface Mount, 1.8V to 5.5V Supply DG2034EDN-T1-GE4

Name: Vishay Multiplexer 4 Single 4:1, 12-Pin QFN Surface Mount, 1.8V to 5.5V Supply DG2034EDN-T1-GE4
Brand: Vishay
SKU: 149153
Price: 1.22 USD
Availability: InStock



Category Multiplexer/Demultiplexer ICs Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	1mm
Length	3mm
Model	DG2034EDN-T1-GE4
Width	3mm
Mount Type	Surface
Series	DG2034E
Configuration	Single 4:1
Maximum Operating Temperature	85°C
Package Type	QFN
Minimum Operating Temperature	-40°C
Standards/Approvals	RoHS
Pin Count	12
Number of Elements per Chip	4
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	1.8V
Multiplexer/Demultiplexer	Multiplexer
Maximum On State Resistance	11Ω
ConfigurationSingle 4	1
Single 4	1
Vishay DG2034EDN-T1-GE4 Multiplexer, 4 Single 4	1, Multiplexer, 12-Pin QFN

Key Features

Operates over a wide supply voltage range from 1.8V to 5.5V.
Compact 3 x 3 mm QFN package with 1mm height for space-efficient PCB layouts.
Maximum on-state resistance of 11Ω minimizes signal loss.
Four multiplexing elements per chip reduce component count.
Supports operating temperature range from -40°C to 85°C for robust industrial use.
Designed for surface-mount installation and reflow soldering processes.
Ideal for multiplexing analog sensors and signal routing in instrumentation and consumer electronics.
Not automotive certified; suitable for commercial and industrial applications.

Product Description

Vishay DG2034EDN-T1-GE4 is a 4 single 4:1 channel analogue multiplexer integrated circuit housed in a compact 12-pin QFN package measuring 3 mm by 3 mm with a low profile height of 1 mm. It operates from a broad supply voltage range between 1.8V and 5.5V, suitable for many commercial and industrial electronic systems requiring signal routing or channel selection.

The device integrates four multiplexing elements per chip, minimizing board component count and facilitating more efficient circuit designs. Its maximum on-state resistance of 11Ω significantly reduces signal degradation. It is intended for surface-mount assembly using reflow soldering and features twelve pins enabling easy PCB integration.

Designed to operate in ambient temperatures from -40°C to 85°C, it is well-suited for industrial instrumentation applications, data acquisition front-ends, and compact consumer electronics. Typical use cases include multiplexing analogue sensors, switching audio routing signals, and other multi-channel signal selection tasks.

While offering robust features, the multiplexer does not carry automotive-grade certification and should not be used in applications requiring such approval. Its RoHS compliance ensures it meets environmental standards.

Operates from 1.8V to 5.5V supply voltage. Low profile 3 mm x 3 mm QFN package with 1 mm height. Four single 4:1 multiplexing elements integrated. Maximum on-resistance of 11Ω for low signal loss. Suitable for surface-mount assembly techniques.

Operating temperature range: -40°C to 85°C. 12 pins for easy PCB integration. Applications include instrumentation, data acquisition, and consumer electronics.

This Vishay multiplexer IC is ideal for engineers and designers requiring compact, high-performance multiplexing solutions in industrial, laboratory, consumer, and commercial electronic systems. Explore more semiconductor devices and components in the EnvMart collection.

Explore more products in our Multiplexer/Demultiplexer ICs category.
