Vishay 20 F Electric Double Layer Supercapacitor 2.7 V 225 EDLC-R Series Through Hole MAL222591003E3
Specifications
| Country of Origin | Austria |
|---|---|
| Voltage | 2.7V |
| Diameter | 16.5mm |
| Brand | Vishay |
| Height | 22mm |
| Model | MAL222591003E3 |
| Packaging | Tray |
| Mount Type | Through Hole |
| Series | 225 EDLC-R |
| Maximum Operating Temperature | 85°C |
| Tolerance | -20 to 50 % |
| Lifetime | 2000 h |
| Capacitance | 20F |
| Minimum Operating Temperature | -40°C |
| Polarity | Polar |
| Terminal type | Radial |
| Leakage Current | 8mA |
| Standards/Approvals | RoHS |
| Package/Case | 19A |
| Pin Count | 2 |
| Lead Pitch | 7.5mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Equivalent Series Resistance ESR | 24mΩ |
| Capacitor Family | Electric Double Layer |
Key Features
- High capacitance electric double layer capacitor with a capacitance of 20 F.
- Polarized radial terminal type with 0.8 mm lead diameter and 7.5 mm lead pitch.
- Rugged design for automotive and industrial environments meeting AEC-Q200 standard.
- Leakage current of 8 mA and equivalent series resistance (ESR) of 24 mΩ for efficient performance.
- Operating temperature range from -40°C to 85°C with a lifetime of approximately 2000 hours.
- Compact dimensions with 16.5 mm diameter and 22 mm height, housed in a 19A package case.
- RoHS compliant and manufactured in Austria ensuring quality and environmental safety.
Product Description
Vishay MAL222591003E3 is a high-capacity 20 F supercapacitor from the 225 EDLC-R series, featuring an electric double layer capacitor technology rated for 2.7 V. This polarized device uses radial terminals and is designed for through-hole mounting, offering rugged reliability and long operational lifetime for energy storage solutions.
This supercapacitor supports power backup and burst power applications, as well as energy harvesting storage in automotive, industrial, and electronic equipment contexts. Its electrical parameters include an equivalent series resistance (ESR) of 24 mΩ and a leakage current of 8 mA, ensuring efficient energy retention and discharge.
The device operates safely within the temperature range of -40°C to 85°C, complying with automotive AEC-Q200 standards. With nominal dimensions of 16.5 mm diameter and 22 mm height, it fits compact PCB layouts while maintaining high energy density and stability.
Vishay's 225 EDLC-R series supercapacitors are RoHS compliant and manufactured in Austria, assuring both environmental compliance and manufacturing excellence. High capacitance electric double layer capacitor with a capacitance of 20 F.
Voltage rating of 2.7 V suitable for energy storage and power backup applications. Polarized radial terminal type with 0.8 mm lead diameter and 7.5 mm lead pitch. Rugged design for automotive and industrial environments meeting AEC-Q200 standard.
Leakage current of 8 mA and equivalent series resistance (ESR) of 24 mΩ for efficient performance. Operating temperature range from -40°C to 85°C with a lifetime of approximately 2000 hours. Compact dimensions with 16.5 mm diameter and 22 mm height, housed in a 19A package case.
RoHS compliant and manufactured in Austria ensuring quality and environmental safety.
This product is ideal for applications requiring durable, high-capacity energy storage including power backup, burst power support, and energy harvesting devices in industrial, automotive, and electronic manufacturing sectors.
Explore more Vishay supercapacitors and electronic components in the EnvMart catalog to suit your project needs and industry requirements.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance of 20 F, making it suitable for high-capacity energy storage applications.
It is rated for a voltage of 2.7 V, which is appropriate for various energy storage and power backup applications.
The supercapacitor has a diameter of 16.5 mm and a height of 22 mm, fitting compact PCB layouts.
The equivalent series resistance (ESR) is 24 mΩ, which contributes to its efficient performance in energy retention and discharge.
It operates safely within a temperature range of -40°C to 85°C, making it suitable for various environmental conditions.
The leakage current is specified at 8 mA, which is an important parameter for energy storage devices.
It features polarized radial terminals with a lead diameter of 0.8 mm and a lead pitch of 7.5 mm for through-hole mounting.
It meets the AEC-Q200 standard, ensuring reliability in automotive applications.
Yes, this model is RoHS compliant, ensuring it meets environmental safety standards.
It is packaged in a tray, which is suitable for efficient handling and integration into electronic systems.
