Microchip 2 Channel 12 bit Successive Approximation Register ADC 100 ksps, 8-Pin SOIC MCP3202-BI/SN
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 12 bit |
| Brand | Microchip |
| Height | 1.44mm |
| Length | 5.01mm |
| Model | MCP3202-BI/SN |
| Mount Type | Surface |
| Sampling rate | 100ksps |
| Series | MCP3202 |
| Input Type | Voltage |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Interface Type | SPI |
| Architecture | SAR |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
| Number of ADCs | 2 |
Key Features
- Utilizes successive approximation register SAR architecture for precise conversion.
- Operates over a wide voltage supply range from 2.7 V to 5.5 V.
- Features 8-pin SOIC surface mount package for PCB integration.
- Suitable for industrial and automotive applications meeting AEC-Q100 standards.
- Can operate at temperatures from -40°C to 85°C.
- Two ADCs integrated, ideal for multi-channel sensing.
- Interface type SPI facilitates communication with microcontrollers.
- Compact physical dimensions of 5.01 mm length and 1.44 mm height.
Product Description
Microchip MCP3202-BI/SN is a high-precision analogue to digital converter featuring 2 ADC channels and a 12 bit resolution. Its successive approximation register (SAR) architecture ensures accurate and efficient conversion of voltage inputs. This product operates with a supply voltage range between 2.7 V and 5.5 V and supports a sampling rate of up to 100 ksps, making it suitable for rapid data acquisition in various electronic designs.
The device is housed in a compact 8-pin SOIC surface mount package, measuring 5.01 mm in length and 1.44 mm in height, which allows easy PCB mounting and integration. It features an SPI interface for straightforward communication with microcontrollers and other digital systems.
Designed to meet the automotive standard AEC-Q100, the MCP3202-BI/SN supports robust operation in challenging environments, with an operating temperature range from -40°C to 85°C. This makes it ideal for use in automotive, industrial control, instrumentation, and other applications requiring reliable voltage conversion and data processing.
The dual ADC channels enable multi-input measurements, enhancing versatility in embedded system projects and instrumentation. The device’s surface mount package type facilitates automated PCB assembly processes increasing production efficiency.
Utilizes SAR architecture for precise analogue to digital conversion. Two integrated ADC channels support multi-signal inputs. SPI communication interface for microcontroller compatibility. Wide operating temperature range from -40°C to 85°C.
Operating voltage range from 2.7 V to 5.5 V. Compact 8-pin SOIC surface mount package for easy PCB integration. Meets automotive standards (AEC-Q100) for industrial reliability. Sampling rate up to 100,000 samples per second (ksps).
This ADC is widely applied in industrial instrumentation, automotive electronics, data acquisition systems, and embedded control units. Its compact dimension and reliable operation under varying conditions make it a preferred choice for engineers designing high-performance digital measurement systems.
Explore more products in the Analogue to Digital Converter category for complementary components and solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP3202-BI/SN features a resolution of 12 bits, allowing for precise analogue to digital conversion.
This model supports a maximum sampling rate of 100,000 samples per second (100 ksps), suitable for rapid data acquisition applications.
It operates over a voltage supply range from 2.7 V to 5.5 V, making it versatile for various applications.
The MCP3202-BI/SN can operate within a temperature range of -40°C to 85°C, suitable for industrial and automotive environments.
This model integrates two ADC channels, allowing for multi-input measurements in embedded systems.
The MCP3202-BI/SN utilizes an SPI interface for communication with microcontrollers and other digital systems.
It has compact dimensions of 5.01 mm in length and 1.44 mm in height, facilitating easy PCB integration.
The MCP3202-BI/SN is housed in an 8-pin SOIC surface mount package, suitable for automated PCB assembly.
Yes, it meets the AEC-Q100 automotive standard, ensuring reliability in automotive electronics.
It employs a successive approximation register (SAR) architecture for accurate and efficient voltage conversion.
The MCP3202-BI/SN supports voltage input types, making it suitable for various measurement applications.
The country of origin for the MCP3202-BI/SN is India.
