Microchip Operational Amplifier 2 MHz Gain Bandwidth Product, 5-Pin SOT-23 Package, 4.5V to 45V Supply MCP6V51T-E/OT

Free Delivery in India | Lowest Global Shipping Charges

Microchip Operational Amplifier 2 MHz Gain Bandwidth Product, 5-Pin SOT-23 Package, 4.5V to 45V Supply MCP6V51T-E/OT

Name: Microchip Operational Amplifier 2 MHz Gain Bandwidth Product, 5-Pin SOT-23 Package, 4.5V to 45V Supply MCP6V51T-E/OT
Brand: Microchip
SKU: 427598
Price: 2.16 USD
Availability: InStock



Category Operational Amplifier Brand Microchip Condition New

Specifications

Country of Origin	Thailand
Brand	Microchip
Height	1.3mm
Length	2.9mm
Model	MCP6V51T-E/OT
Width	1.6mm
Mount Type	Surface
Series	MCP6V51
Output Current	50mA
Maximum Operating Temperature	125°C
Package Type	SOT-23
Minimum Operating Temperature	-40°C
Number Of Channels	1
Standards/Approvals	RoHS
Pin Count	5
Maximum Supply Voltage	45V
Minimum Supply Voltage	4.5V
GBP - Gain Bandwidth Product	2MHz
Input Bias Current	250 pA
Slew Rate	1.2V/μs
Input Offset Current	1 nA
Wide operating range	4.5V to 45V

Key Features

Features zero-drift architecture for minimal offset voltage and drift.
Operates over a wide supply voltage range from 4.5V to 45V.
Provides a gain bandwidth product of 2 MHz suitable for precision applications.
Has a low input bias current of 250 pA and input offset current of 1 nA.
Unity gain stable amplifier with no 1/f noise for clean signal amplification.
Maximum output current of 50 mA supports moderate load driving capability.
Small 5-pin SOT-23 surface mount package with dimensions 2.9 mm length, 1.6 mm width, and 1.3 mm height.
Operating temperature range from -40°C to 125°C for industrial reliability.

Product Description

Microchip MCP6V51T-E/OT is a high-performance operational amplifier designed for precision and stability. Featuring a zero-drift architecture, it achieves exceptionally low input offset voltage of ±15 μV and offset voltage drift of 36 nV/°C. This amplifier operates with a wide supply voltage range from 4.5V up to 45V, making it suitable for diverse electronic designs requiring high voltage tolerance.

The device provides a gain bandwidth product (GBWP) of 2 MHz, making it ideal for applications that demand precision signal amplification with unity gain stability and no 1/f noise interference. With an input bias current of just 250 pA and offset current of 1 nA, it ensures minimal signal distortion, enhancing overall circuit accuracy.

Packaged in a compact 5-pin SOT-23 surface mount package (2.9 mm x 1.6 mm x 1.3 mm), the MCP6V51T-E/OT is suitable for space-constrained applications and is RoHS compliant. Its output current capability of up to 50 mA enables driving of moderate loads directly.

The operational amplifier supports a broad operating temperature range from -40°C to 125°C, confirming its robustness for industrial, laboratory, and automotive electronics applications. Enhanced EMI rejection features improve its reliability in electrically noisy environments.

Zero-drift architecture minimizes offset voltage and drift. Wide supply voltage from 4.5V to 45V for versatile system integration. High gain bandwidth product of 2 MHz for precision amplification. Low input bias and offset currents reducing signal errors.

Compact 5-pin SOT-23 surface mount package for space efficiency. RoHS compliant ensuring environmental safety. Operating temperature range of -40°C to 125°C for industrial use. Output current capability of 50 mA for load driving.

Enhanced EMI rejection for stable operation in noisy conditions.

This operational amplifier is ideal for industrial, laboratory, electronics manufacturing, instrumentation, and other commercial applications requiring reliable and accurate amplification.
