Vishay 400 V 70 A Standard Recovery Diode Screw Mount DO-5 Package VS-70HFLR40S02
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 14.6mm |
| Brand | Vishay |
| Height | 22.9mm |
| Length | 20.08mm |
| Model | VS-70HFLR40S02 |
| Width | 17.4mm |
| Mount Type | Screw |
| Series | VS-70HF(R) |
| Maximum Operating Temperature | 125°C |
| Package Type | DO-5 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 70A |
| Peak Reverse Repetitive Voltage Vrrm | 400V |
| Diode Configuration | Stud Anode |
| Rectifier Type | Recovery |
| Peak Reverse Current Ir | 15mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 1250A |
| Maximum Forward Voltage Vf | 1.85V |
| Peak Reverse Recovery Time trr | 200ns |
| Vishay 200 V 70 A Diode Switching 2-Pin DO-203ABBrand | Vishay |
| Vishay 400V 70A, Silicon Junction Diode, 2-Pin DO-5 VS-70HFL40S05Brand | Vishay |
Key Features
- The diode features a 2-pin stud anode configuration.
- Maximum forward voltage drop is 1.85 V ensuring low power losses.
- Peak eclipse recovery time is 200 ns suitable for fast switching applications.
- Operates reliably between temperatures of -40°C and 125°C.
- The diode supports peak non-repetitive forward surge current of 1250 A.
- This device complies with RoHS standards for environmental safety.
Product Description
Vishay VS-70HFLR40S02 is a high-performance Standard Recovery Diode specifically engineered for power semiconductor applications. It is housed in a robust DO-5 package with screw mount capability ensuring easy installation and mechanical stability in industrial and commercial electronics.
This diode provides a maximum continuous forward current rating of 70 A and a peak reverse repetitive voltage of 400 V. Designed with a stud anode diode configuration and featuring a recovery rectifier type, it ensures efficient conduction and fast recovery, making it suitable for power rectification and switching purposes.
The device exhibits a maximum forward voltage drop of 1.85 V which translates to lower conduction losses and improved energy efficiency. Its reverse recovery time of 200 ns enables reliable operation in circuits requiring fast switching frequency, typical in power supply units and motor control circuits.
Operating temperature range between -40°C and 125°C allows reliable performance across varied environmental conditions. The diode can withstand peak non-repetitive forward surge current up to 1250 A, providing durability under transient overload conditions.
Compact dimensions (22.9 mm height, 20.08 mm length, 17.4 mm width, 14.6 mm diameter) allow integration in space-constrained applications. Compliance with RoHS environmental standards assures users of its minimal environmental impact.
This product is well-suited for industrial, manufacturing, electrical power control systems, and electronics repair or assembly tasks requiring reliable recovery diodes. The diode features a 2-pin stud anode configuration.
Maximum forward voltage drop is 1.85 V ensuring low power losses. Peak eclipse recovery time is 200 ns suitable for fast switching applications. Operates reliably between temperatures of -40°C and 125°C. The diode supports peak non-repetitive forward surge current of 1250 A.
Dimensions are compact with height 22.9 mm, length 20.08 mm, width 17.4 mm, and diameter 14.6 mm. This device complies with RoHS standards for environmental safety. Explore the Vishay product range on EnvMart for additional semiconductor solutions and robust power components.
Explore more products in our Standard Recovery Switching Diode category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating for this model is 70 A.
This diode has a peak reverse repetitive voltage of 400 V.
The peak reverse recovery time for this unit is 200 ns, making it suitable for fast switching applications.
It operates reliably between temperatures of -40°C and 125°C.
The maximum forward voltage drop is 1.85 V, which helps ensure low power losses.
This model features a screw mount configuration, allowing for easy installation.
The dimensions are 22.9 mm in height, 20.08 mm in length, 17.4 mm in width, and a diameter of 14.6 mm.
The diode supports a peak non-repetitive forward surge current of 1250 A.
Yes, this device complies with RoHS standards for environmental safety.
It features a stud anode configuration, which is typical for power semiconductor applications.
The rectifier type for this model is recovery, suitable for power rectification and switching purposes.
This diode is well-suited for industrial, manufacturing, electrical power control systems, and electronics repair or assembly tasks.
