Molex SPOX Series Right Angle Through Hole PCB Header, 2 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 22-05-7025

Free Delivery in India | Lowest Global Shipping Charges

Molex SPOX Series Right Angle Through Hole PCB Header, 2 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 22-05-7025

Name: Molex SPOX Series Right Angle Through Hole PCB Header, 2 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 22-05-7025
Brand: Molex
SKU: 212109
Price: 0.22 USD
Availability: InStock



Category PCB Header Brand Molex Condition New

Specifications

Country of Origin	China
Voltage	250V
Brand	Molex
Orientation	Right Angle
Current	3A
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	SPOX
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	2.5mm
Contact Plating	Tin
Number of Contacts	2
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.5mm

Key Features

Designed for durable wire-to-board connection with a right-angle orientation.
Rated for 3A current and 250V voltage for reliable performance.
Constructed with nylon housing for thermal stability and brass contacts with tin plating.
Shrouded and friction lock system enhances secure mating and alignment.
Compatible with 1 row and 2.5 mm row pitch PCBs.
Suitable for automation and electrical circuitry requiring compact header solutions.
Supports PCB thickness recommendation of 1.60 mm for optimal fit.
Mates with 5264 SPOX wire-to-board crimp housings designed for through-hole termination.

Product Description

Molex 22-05-7025 SPOX Series Right Angle Through Hole PCB Header provides a robust wire-to-board connection solution. Featuring 2 contacts with a 2.5 mm pitch and single row configuration, this header is shrouded to guide cable insertion, ensuring secure and reliable mechanical and electrical connections.

Manufactured with a durable nylon resin housing, the header offers improved thermal stability suitable for harsh environments. The brass contacts plated with tin deliver reliable conductivity and corrosion resistance. The unit is designed for through-hole mounting with a tail pin length of 3.5 mm, making it ideal for solder termination.

With an operating current rating of 3A and voltage rating of 250V, this header supports signal and low power transfer in industrial automation, electronic device assembly, and electrical equipment wiring. It includes a friction lock system for firm connectivity, reducing the risk of accidental disconnection.

The recommended PCB thickness for installation is 1.60 mm, optimizing mechanical fit and electrical performance. This header mates with the 5264 SPOX wire-to-board crimp housing series specifically engineered for through-hole terminations, ensuring compatibility and ease of assembly.

Durable right angle header with shrouded design for secure connections. Rated for 3A current and 250V voltage for versatile electronics use. Constructed from nylon housing and brass contacts with tin plating. Friction lock mechanism guarantees reliable mating in circuits.

Compatible with 2.5 mm pitch and 1 row PCB configuration. Suitable for automation and electrical equipment applications. Recommended PCB thickness is 1.60 mm for optimal performance. Mates with 5264 SPOX crimp housings designed for through-hole mounting.

This PCB Header is widely applicable in industrial, commercial, and automation systems requiring compact, reliable wire-to-board connectors. Explore EnvMart’s extensive range of electronic connectors and components designed to meet rigorous industrial standards.
