Molex Milli-Grid Series Straight Surface PCB Header 12 Contacts 2 mm Pitch 2 Row Shrouded 87832-1220

Molex 87832-1220 Milli-Grid Series Straight Surface PCB Header is a high-quality electronic connector designed for board-to-board and cable-to-board interconnections. This shrouded header features 12 contacts in a dual-row layout with a 2 mm pitch, ensuring precise and secure connections for reliable performance in various electronic applications.

The connector housing is made of robust nylon, which provides excellent electrical insulation and mechanical durability. The contacts are composed of phosphor bronze and finished with a 0.38 μm gold plating to optimize electrical conductivity and resistance to corrosion, enhancing product longevity.

Rated for 2A current at 125V, this PCB header is suitable for medium power electronic applications. It supports surface mount technology with a straight orientation, and solder termination ensures secure attachment to printed circuit boards. Its operating temperature range spans from -55°C to 105°C, allowing use in demanding industrial, manufacturing, and electronic environments.

The mating pin length of 2 mm is designed for compatibility with Molex 51110 Series receptacles, facilitating flexible design choices in assembly. The shrouded design reduces the risk of bent pins and misalignment, improving reliability during installation and operation.

Features 12 contacts arranged in 2 rows with 2 mm pitch for high-density connectivity. Constructed with durable nylon housing for electrical insulation and mechanical strength. Contact material is phosphor bronze with gold plating to ensure excellent conductivity and corrosion resistance.

Rated for 2A current at 125V voltage, suitable for moderate power applications. Designed for surface mount technology with straight orientation and solder termination. Operates reliably in temperatures ranging from -55°C to 105°C.

Mating pin length is 2 mm, compatible with mating receptacles in the 51110 Series. Shrouded header design provides protection against misalignment during mating. Ideal for wire-to-board applications in electronic devices and industrial electronics.

Meets industry standards though no specific approvals are listed.

This PCB header is widely applicable in industrial electronics, manufacturing, laboratory equipment, and electronic device assemblies requiring dependable wire-to-board connections. Its reliable design supports high-density configurations and ensures secure electrical conduction under various operating conditions.
