Molex 0.5 mm Pitch 12 Way Right Angle Male FPC Connector Surface Mount Solder Termination 505110-1292

Molex 505110-1292 is a high-quality 0.5 mm pitch Right Angle Male FPC Connector, designed for surface mounting with solder termination. This connector features a double-bottom contact design that provides a clean mating interface ensuring high contact reliability and easy insertion with Zero Insertion Force (ZIF). It is engineered for use in compact spaces where tight packaging is necessary.

The connector has 12 contacts made of phosphor bronze with gold over nickel plating, providing excellent conductivity and durability. The housing is constructed from liquid crystal polymer material, offering thermal resistance up to 105°C and mechanical stability. Cable ear-tab locking ensures proper seating and alignment, providing high retention force and secure connections.

This Molex connector supports up to 50V voltage and 500mA current capacity, suitable for various industrial, automotive, consumer electronics, and data communication applications. Its compact low profile with a mating height of just 1.9 mm facilitates space-saving designs without compromising reliability.

Additional features include solder tabs for robust PCB retention and strain relief, and a vacuum pick and place area on the housing top for efficient automated assembly and cost savings.

Applications span across automotive display audio, car navigation systems, consumer electronics such as flat panel TVs, portable game consoles, personal navigation equipment, and data communications including optical disk drives, tablets, notebook PCs, printers, and copiers.

Features 12 contacts with phosphor bronze contact material for durability. Compact 0.5 mm pitch and right angle orientation suitable for tight packaging. Zero Insertion Force (ZIF) design allows easy cable insertion and repeat cycling.

Gold over nickel contact plating ensures excellent conductivity and corrosion resistance. Housing made from liquid crystal polymer for high temperature tolerance up to 105°C. Cable ear-tab locking feature provides strong retention and alignment.

Surface mount type for easy PCB assembly and secure solder joints. Operating voltage rated at 50V and current capacity of 500mA. Minimum operating temperature of -40°C supports robust industrial applications. Compact low profile design with a mating height of 1.9 mm for space saving.
