Wurth Elektronik WR-FPC 1 mm Pitch 10 Way Vertical Female FPC Connector Surface Mount 686110183822

Wurth Elektronik 686110183822 FPC Connector is a 1 mm pitch 10 way vertical female connector designed for surface mount technology applications. This ZIF (Zero Insertion Force) connector provides a secure and reliable electrical connection using a slide lock actuator that simplifies assembly and enhances retention force.

The contact material is phosphor bronze with tin over nickel plating, ensuring excellent conductivity and corrosion resistance. The connector supports a current of 1A and withstands up to 125V AC, making it suitable for low power applications.

The polyamide housing material offers robust mechanical strength and thermal stability, functioning reliably between -25°C and 85°C. Its single row contact arrangement and vertical orientation make it perfect for compact PCB designs in miniaturized high-density electronics.

Applications include display technologies, touch screen panels, personal computing devices, tablets, mobile phones, cameras, and various industrial, medical, and business equipment. The WR-FPC series connectors from Wurth Elektronik are renowned for their compact design and ease of use.

This connector features a slide lock actuator for easy insertion and high retention force. It has 10 contacts with phosphor bronze contact material and tin over nickel plating. The connector supports a current rating of 1A and a voltage rating of 125V AC.

Constructed with a polyamide housing for durability and stability under varied temperatures. It is ideal for high-density applications including displays, touch panels, and consumer electronics. The vertical orientation and single row design allow compact PCB layouts.

The connector operates reliably within a temperature range from -25°C to 85°C. Explore more Wurth Elektronik FPC Connectors to find solutions optimized for industrial, medical, and consumer electronic designs on EnvMart.
