KEMET Polypropylene Capacitor 22nF 5% Tolerance 1kV DC 250V AC Through Hole R75QI222050H0J
Specifications
| Country of Origin | China |
|---|---|
| Brand | KEMET |
| Height | 11mm |
| Length | 18mm |
| Model | R75QI222050H0J |
| Packaging | Tape & Reel |
| Width | 5mm |
| Mount Type | Through Hole |
| Series | R75 |
| Maximum Operating Temperature | 105°C |
| Tolerance | 5 % |
| Capacitance | 22nF |
| Minimum Operating Temperature | -55°C |
| Dissipation Factor | 0.04% |
| Lead Length | 25mm |
| Standards/Approvals | IEC 60286-2, RoHS |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 250V ac |
| Rated DC Voltage | 1kV dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Equivalent Series Resistance ESR | 50.6mΩ |
Key Features
- Rated for 250V AC and 1kV DC voltage applications.
- 5% capacitance tolerance ensures precise electrical performance.
- Constructed with plastic self-extinguishing case with thermosetting resin.
- Through-hole mount type with 15mm lead pitch for easy PCB installation.
- Operating temperature range from -55°C to 105°C for versatility in various environments.
- Low dissipation factor of 0.04% for efficient energy usage.
- Automotive grade compliant with AEC-Q200 standards.
- Lead diameter of 0.8mm and lead length of 25mm for secure connections.
Product Description
KEMET R75QI222050H0J Polypropylene Capacitor is a high-reliability film capacitor designed for medium to high-frequency electronic applications, where stable capacitance and low loss are critical. It features a capacitance value of 22nF with a tolerance of 5%, supporting operating voltages of 1 kV DC and 250 V AC, making it suitable for demanding industrial and automotive circuits.
The capacitor uses a metallized polypropylene film encapsulated within a self-extinguishing plastic case with thermosetting resin, ensuring excellent insulation and durability. Its radial lead design and through-hole mounting style facilitate straightforward printed circuit board installation with a 15 mm lead pitch and robust lead wires measuring 0.8 mm in diameter and 25 mm in length.
Designed to operate reliably over a broad temperature range from -55°C to 105°C, this film capacitor offers low equivalent series resistance (ESR) of 50.6 mΩ and a dissipation factor of just 0.04%, contributing to minimal energy loss and heat generation during operation.
It complies with automotive standard AEC-Q200 and international standards including IEC 60286-2, and RoHS, ensuring high quality and environmental compliance. The compact dimensions of 18 mm length, 11 mm height, and 5 mm width allow it to be used in space-constrained environments.
The KEMET R75 series is ideal for use in resonant circuits, silicon controlled rectifiers, and general high-frequency power electronic applications requiring stable capacitance and robust construction.
Rated AC Voltage: 250V AC and DC Voltage: 1kV DC for high voltage applications. Low dissipation factor and ESR for energy-efficient operation. Wide operating temperature range suitable for industrial and automotive environments.
Plastic self-extinguishing case with lead-free terminations for safety and environmental compliance. Through-hole mounting for reliable PCB assembly. AEC-Q200 automotive standard ensures suitability for automotive electronics.
RoHS compliant material and design.
This polypropylene film capacitor is a reliable choice for industrial, automotive, and electronic manufacturing sectors. Explore more KEMET capacitors and related electronic components in the EnvMart Electronics & Electricals category for your project needs.
Explore more products in our Film Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 22nF with a tolerance of 5%.
It is rated for 1kV DC and 250V AC voltage applications.
The operating temperature range is from -55°C to 105°C.
The lead length is 25mm and the lead diameter is 0.8mm.
This model uses a through-hole mounting type with a lead pitch of 15mm.
The equivalent series resistance (ESR) is 50.6 mΩ.
It complies with AEC-Q200, IEC 60286-2, and is RoHS compliant.
It features a plastic self-extinguishing case with thermosetting resin.
The dissipation factor is 0.04%.
The dimensions are 18mm in length, 11mm in height, and 5mm in width.
It is suitable for medium to high-frequency electronic applications, including resonant circuits and silicon controlled rectifiers.
It is packaged in tape and reel format for easy handling and assembly.
