KEMET R60 Film Capacitor 330nF 250V DC 160V AC Through Hole ±10% R60II33305030K
Specifications
| Country of Origin | North Macedonia |
|---|---|
| Capacitance Range | 0.001 μF - 150.0 μF |
| Brand | KEMET |
| Height | 11mm |
| Length | 18mm |
| Model | R60II33305030K |
| Packaging | Bulk |
| Width | 5mm |
| Mount Type | Through Hole |
| Series | R60 |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±10 % |
| Capacitance | 330nF |
| Minimum Operating Temperature | -55°C |
| Climatic category | 55/105/56 |
| Terminal type | Solder |
| Dissipation Factor | 1.5% |
| Lead Length | 25mm |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Rated AC Voltage | 160V ac |
| Rated DC Voltage | 250V dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Capacitance tolerance | ±5%, ±10%, ±20% |
| Lead Spacing | 10.0 - 37.5 mm |
Key Features
- 330nF capacitance with ±10% tolerance for stable circuit performance.
- Rated for 250V DC and 160V AC, suitable for diverse applications.
- Through hole mounting type with 15mm lead pitch and 25mm lead length.
- Constructed from metallized polyester film for reliability and self-healing.
- AEC-Q200 automotive compliance ensures durable operation.
- Wide operating temperature range from -55°C to +105°C.
- Solder terminal leads for straightforward PCB assembly.
- RoHS compliant for international safety requirements.
Product Description
The KEMET R60II33305030K is a high reliability film capacitor featuring a 330nF capacitance and ±10% tolerance. Designed for through hole mounting, it supports both 250V DC and 160V AC voltages, making it suitable for a wide variety of electronic circuit applications, including filtering, coupling, decoupling, and bypassing.
This capacitor is constructed using metallized polyester film in a wound or stacked configuration. It features radial leads made of tinned wire, electrically welded to the contact layer at each end for optimal electrical performance. The body is encapsulated in thermosetting resin within a robust rectangular box material, providing high mechanical stability and self-healing properties.
The R60 series is AEC-Q200 compliant, meaning it meets automotive-grade standards for demanding environments. The capacitor is designed to function reliably within operating temperatures ranging from -55°C to +105°C and is suitable for circuits where durability is crucial. Lead spacing is 15mm, lead length is 25mm, and the terminal type is solder, simplifying integration into printed circuit boards. Lead diameter measures 0.8mm, pin count is 2.
Dimensions are compact, with a length of 18mm, width of 5mm, and height of 11mm, allowing installation in tightly packed assemblies. The dissipation factor is rated at 1.5%, and the product is RoHS-certified for environmental safety. The R60 series supports a capacitance range from 0.001µF to 150µF, with lead spacing options between 10mm and 37.5mm. Available packaging is bulk, accommodating high-volume manufacturing and assembly.
Typical applications include bypassing, blocking, coupling, and decoupling in signal and power circuits, both for automotive and industrial use. It is suitable for power supplies, control modules, and demanding electronic systems in environments where consistent reliability is critical.
The KEMET R60II33305030K Film Capacitor connects seamlessly to the Film Capacitors category, supporting engineers and manufacturers in advanced electronics. Explore the KEMET range for more high-performance capacitors and related passive electronic components on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The KEMET R60II33305030K has a capacitance value of 330nF.
It is rated for 250V DC and 160V AC, making it suitable for various electronic applications.
This capacitor has a capacitance tolerance of ±10%.
The dimensions of this model are 18mm in length, 5mm in width, and 11mm in height.
The lead pitch is 15mm, and the lead length is 25mm.
It operates within a temperature range of -55°C to +105°C.
This model is designed for through hole mounting.
The dissipation factor is rated at 1.5%.
It is RoHS compliant and meets AEC-Q200 automotive standards.
This model has a pin count of 2.
It features solder terminal leads for easy integration into printed circuit boards.
It is suitable for applications such as filtering, coupling, decoupling, and bypassing in electronic circuits.
