Molex Milli-Grid Series Straight Surface PCB Header, 10 Contact, 2 mm Pitch, 2 Row, Shrouded 87832-1010

Molex 87832-1010 is a high-quality Milli-Grid Series straight surface mount PCB header featuring 10 contacts arranged in 2 rows with a 2 mm pitch. This shrouded header is designed with a robust nylon housing and male phosphor bronze contacts plated with 0.38 µm gold to ensure excellent electrical conductivity and resistance to corrosion. The product is rated for a maximum operating temperature of 105°C and can function reliably in environments as cold as -55°C.

This 2.0 mm pitch connector is designed for wire-to-board applications and mounts securely using solder termination, making it suitable for SMT assembly processes. It is rated for 2 A current and 125 V voltage, supporting a wide range of electronic circuit requirements.

The shrouded design enhances mating reliability by providing polarization and protection against misalignment. Tail pin length is 2.5 mm, and the mating pin length is 2 mm, ensuring secure mechanical and electrical connections with corresponding Molex 51110 Series receptacles.

This PCB header system supports high-density interconnections typically required in consumer electronics, industrial controls, and communication equipment. Its compact 2 x 2 mm grid pattern offers design flexibility for multipin PCB assemblies.

Applications include industrial, commercial, and laboratory electronics where reliable, compact, and high-performance PCB connectors are essential. The header has 10 male contacts arranged in 2 rows with a 2 mm pitch. Constructed with a nylon housing for durability and electrical insulation.

Contacts are made from phosphor bronze and plated with 0.38 µm gold for corrosion resistance and conductivity. Designed for surface mount technology (SMT) with a wire-to-board connector system. Operates reliably between -55°C and 105°C temperature range.

Rated for 125 V voltage and 2 A current capacity. Tail pin length is 2.5 mm; mating pin length is 2 mm for secure connections. Shrouded design provides protection and polarization for reliable mating. Ideal for high density PCB interconnection applications.

Compatible with Molex 51110 Series receptacles. Explore more PCB Headers by Molex and related connector solutions at EnvMart for your electronics manufacturing and design needs.
