STMicroelectronics NPN Darlington Transistor 4 A 60 V 750 hFE 40 W Power Dissipation SOT-32 BD677
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 10.8mm |
| Length | 7.8mm |
| Model | BD677 |
| Mount Type | Through Hole |
| Series | BD677 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-32 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Maximum Continuous Collector Current Ic | 4A |
| Maximum Collector Emitter Voltage Vceo | 60V |
| Number of Elements per Chip | 1 |
| Minimum DC Current Gain hFE | 750 |
| Transistor Polarity | NPN |
| Maximum Emitter Base Voltage VEBO | 5V |
| Maximum Collector Emitter Saturation Voltage VceSAT | 2.5V |
| Maximum Collector Base Voltage VCBO | 60V |
| Maximum Collector Cut-off Current | 0.2mA |
| Maximum Power Dissipation Pd | 40W |
| onsemi BD677AG NPN Darlington Transistor, 4 A 60 V HFE | 750, 3-Pin TO-225Brand: ON Semiconductor |
| STMicroelectronics 1 Darlington Transistor NPN, 4 A 60 V HFE | 750, 3-Pin SOT-32 |
Key Features
- Maximum continuous collector current of 4 A for efficient switching performance.
- Collector-emitter voltage rating of 60 V suitable for medium voltage applications.
- High DC current gain (hFE) of 750 ensuring amplification efficiency.
- Package type SOT-32 with 3 pins for through-hole mounting ease.
- Maximum power dissipation of 40 W supports high power handling.
- Operating temperature range from -65°C to 150°C for reliable operation in varying environments.
- Low collector cut-off current of 0.2 mA minimizes leakage current losses.
- Designed with NPN transistor polarity for standard switching functionality.
Product Description
STMicroelectronics BD677 is a high-performance NPN Darlington Transistor designed for power amplification and switching applications in electronic circuits. Rated at a continuous collector current of 4 A and a maximum collector-emitter voltage of 60 V, it is suitable for medium power electronic applications requiring robustness and reliability.
The transistor features a high current gain (hFE) of 750, which provides excellent amplification capabilities. It comes in a SOT-32 package with 3 pins, supporting through-hole mounting processes common in circuit boards.
With a maximum power dissipation capability of 40 W, this transistor ensures efficient operation under demanding power conditions. Its operational temperature range from -65°C to 150°C makes it well-suited for industrial, automotive, and commercial electronics working in various thermal environments.
The maximum collector-emitter saturation voltage of 2.5 V and low collector cut-off current of 0.2 mA enhance switching efficiency by reducing power losses during operation. Its compact physical dimensions (7.8 mm length and 10.8 mm height) facilitate integration in space-conscious layouts.
Typical uses include power amplification in audio circuits, switching applications in control devices, and as a component in driver circuits in industrial and automotive electronics. It is a reliable choice for designers looking to achieve robust performance in discrete semiconductor device applications.
Maximum continuous collector current of 4 A. Maximum collector-emitter voltage of 60 V. High DC current gain (hFE) of 750. SOT-32 package with 3-pin through-hole mounting. Maximum power dissipation of 40 W. Operating temperature range from -65°C to 150°C.
Low collector cut-off current of 0.2 mA. NPN transistor polarity. Compact physical dimensions: 7.8 mm length, 10.8 mm height. Maximum collector-emitter saturation voltage of 2.5 V. Explore EnvMart's extensive selection of semiconductor components and discrete transistors for your next industrial or commercial electronics project.
