Molex Micro-Fit 3.0 Series Straight Through Hole PCB Header, 8 Contacts, 3 mm Pitch, 2 Row, Shrouded 43045-0827

The Molex 43045-0827 is a Micro-Fit 3.0 Series dual row PCB header designed for through hole mounting. Featuring 8 contacts with a 3 mm pitch, this shrouded male connector utilizes brass contacts plated with tin, ensuring robust electrical performance and reliable connections in various industrial and electronic applications.

Constructed from high temperature thermoplastic, the housing withstands IR reflow soldering temperatures up to 265°C, suitable for modern PCB assembly processes. Its design incorporates positive latching housing with a locking ramp to secure the connector mating and prevent inadvertent disconnection, enhancing reliability in operational settings.

With a rated current of 8.5A and voltage capacity of 600V, this PCB Header supports medium power circuits and is suitable for demanding temperature ranges from -40°C to 105°C. The connector features a dual row 3 mm pitch layout with PCB polarizing pegs for accurate positioning and alignment on PCB boards. The through hole design also offers compatibility with SMT processes, reducing production complexity and cost.

Ideal for varied industrial uses including military COTS, solar power systems, consumer appliances, data communications equipment such as routers and servers, medical devices, telecommunications, and gaming terminals. The connector’s manufacturing origin is Mexico, assuring compliance with quality standards.

Features include high current capacity in a compact size, fully isolated dual beam terminals to reduce arcing, glow wire compliance, and kinked solder legs for enhanced PCB retention. This product is a reliable choice for power distribution with secure, high-quality connections.

Designed for low to mid-range power distribution with a compact footprint. Features 8 brass contacts with tin plating for reliable conductivity. Shrouded housing made from thermoplastic for high temperature resistance. Through hole mounting compatible with SMT processes for cost effective assembly.

Supports operating temperatures from -40°C to 105°C for demanding environments. Offers current carrying capacity of up to 8.5A and 600V voltage rating. Incorporates positive latching to prevent accidental disconnections.

Dual row design with 3 mm pitch and PCB polarizing pegs for precise alignment. Explore more PCB connectors and power distribution components in the Electronics & Electricals category at EnvMart.
