Nexperia 2-Element Bi-Directional ESD Protection Diode, 350 W, 3-Pin SOT-23 PESD3V3L2BT,215

Name: Nexperia 2-Element Bi-Directional ESD Protection Diode, 350 W, 3-Pin SOT-23 PESD3V3L2BT,215
Brand: Nexperia
SKU: 122712
Price: 0.17 USD
Availability: InStock



Category ESD Protection Diode Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1mm
Length	3mm
Model	PESD3V3L2BT,215
Width	1.4mm
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Number of Elements per Chip	2
Clamping Voltage VC	26V
Diode Configuration	Series
Direction Type	Bi-Directional
Minimum Breakdown Voltage Vbr	5.8V
Maximum Reverse Stand-off Voltage Vwm	3.3V
Peak Pulse Power Dissipation Pppm	350W
Test Current It	5mA
Maximum Peak Pulse Current Ippm	15A
Maximum Reverse Leakage Current	2μA

Key Features

The diode features a peak pulse power dissipation of 350 watts for effective surge protection.
It supports bidirectional ESD protection, suitable for sensitive electronic circuits.
Minimum breakdown voltage is 5.8 volts with a maximum reverse stand-off of 3.3 volts.
The device includes 2 elements per chip and has a clamping voltage of 26 volts.
It operates reliably between -65°C to 150°C temperature range.
Compact footprint with dimensions of 3 mm length, 1.4 mm width, and 1 mm height.
Designed for surface mount technology with a 3-pin SOT-23 package.
Maximum peak pulse current rating is 15 amperes with very low leakage current of 2 microamperes.

Product Description

The Nexperia PESD3V3L2BT,215 is a 2-element bi-directional ESD Protection Diode engineered to shield electronic components from electrostatic discharge and transient voltage spikes. It is housed in a compact SOT-23 surface-mount package, providing an efficient footprint for PCB integration.

This diode delivers a robust peak pulse power dissipation of 350 watts, ensuring reliability during transient surge conditions. The bidirectional configuration safeguards up to two signal lines simultaneously, making it ideal for protecting sensitive data or power circuits.

Operating within a broad temperature range of -65°C to 150°C, this device is suitable for harsh industrial and electronic environments. The electrical specifications include a minimum breakdown voltage of 5.8 V, maximum reverse stand-off voltage of 3.3 V, and a clamping voltage of 26 V, which effectively limits voltage spikes.

The PESD3V3L2BT,215 offers a maximum peak pulse current of 15 A with minimal leakage current at 2 μA, enhancing device longevity and circuit performance. Its small dimensions (3 mm length, 1.4 mm width, 1 mm height) facilitate high-density PCB layouts without compromising protection capabilities.

This diode is widely used in industrial, communication, consumer electronics, and computing applications requiring electrostatic discharge protection. Its surface mount (SOT-23) package simplifies automated assembly processes.

Peak pulse power dissipation of 350 W ensures robust surge protection. Bidirectional ESD protection for two signal lines offers versatile application. Compact 3-pin SOT-23 surface mount package for space-saving PCB design.

Wide operating temperature range from -65°C to 150°C for reliability in extremes. Low leakage current of 2 μA preserves circuit integrity. Maximum peak pulse current rating at 15 A accommodates transient surges. Manufactured in China with industrial-grade quality standards.

For more electronic components and ESD protection solutions, browse the Electronics & Electricals Semiconductor category at EnvMart for quality and variety.
