Molex Micro-Lock Plus Series Straight Surface PCB Header, 5 Contacts, 1.25 mm Pitch, Single Row, Shrouded 505568-0571

Free Delivery in India | Lowest Global Shipping Charges

Molex Micro-Lock Plus Series Straight Surface PCB Header, 5 Contacts, 1.25 mm Pitch, Single Row, Shrouded 505568-0571

Name: Molex Micro-Lock Plus Series Straight Surface PCB Header, 5 Contacts, 1.25 mm Pitch, Single Row, Shrouded 505568-0571
Brand: Molex
SKU: 217577
Price: 1.1 USD
Availability: InStock



Category PCB Header Brand Molex Condition New

Specifications

Country of Origin	Malaysia
Voltage	50V
Brand	Molex
Orientation	Straight
Current	1.5A
Mount Type	Surface
Housing Material	Polyamide
Contact Material	Brass
Series	Micro-Lock Plus
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	1.25mm
Contact Plating	Tin
Number of Contacts	5
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

Designed for compact, high-temperature applications requiring mechanical and electrical reliability.
Features a polyamide housing and brass contacts with tin plating for enhanced durability.
Operates reliably between -40°C and 105°C temperature range.
Supports a current rating of 1.5 amperes and a voltage rating of 50 volts.
Surface mount type with solder termination offers easy assembly on PCB.
Shrouded structure ensures protected contact housing and male contact gender.
Ideal for automotive, industrial automation, consumer electronics, and other demanding environments.

Product Description

The Molex 505568-0571 Micro-Lock Plus Series Straight Surface PCB Header is a high-quality wire-to-board connector designed to provide excellent electrical and mechanical reliability in compact applications. Featuring a single row of 5 male contacts positioned at a precise 1.25 mm pitch, this shrouded header ensures secure and protected connections on PCBs.

Constructed with a durable polyamide housing and brass contacts plated with tin, it is engineered for high-temperature tolerance from -40°C up to 105°C, making it suitable for automotive and industrial use cases requiring dependable performance under stress.

This connector supports up to 1.5A current and 50V voltage, and it is equipped with solder termination for easy surface mounting on printed circuit boards. Its straight orientation and shrouded design contribute to reliable mating and mechanical protection.

Applications include automotive steering wheels, paddle shift assemblies, combination switches, shifters, head and mirror lights, as well as industrial automation equipment, gaming machines, drones, household appliances such as air conditioners and vacuum cleaners, and office equipment like laser printers.

Durable polyamide housing and high-quality brass contact material ensure longevity and performance. Temperature range from -40°C to 105°C for reliable operation in extreme environments. Compact 5-contact design with 1.25 mm pitch for space-efficient wiring solutions.

Shrouded, straight, surface mount header for secure and easy PCB connection. Voltage rating of 50V and current rating of 1.5A suitable for varied electronics applications. Ideal for automotive, consumer, industrial, and commercial device integrations.

Meets industry standards while supporting varied connector color codings for assembly aid.

This Micro-Lock Plus PCB Header by Molex is a trusted component for design engineers aiming for compact, robust electrical connections in demanding industrial and consumer environments. Explore our PCB Header category for more connector solutions.
