Molex KK 254 Series Right Angle Through Hole Pin Header 5 Contact 2.54 mm Pitch 1 Row Unshrouded 22-12-2054
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 4A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 254 |
| Termination Type | Solder |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
Key Features
- Designed for wire-to-board connection with right angle orientation.
- Constructed with brass contacts plated in gold for optimal conductivity.
- Features a nylon housing material rated UL 94V-0 for flame resistance.
- Supports a maximum operating voltage of 250V and current rating of 4A.
- Suitable for solder termination through hole mounting.
- Operating temperature range from -40°C to 80°C ensures reliability in varied environments.
- Unshrouded design allows easy access and mating with compatible housings.
- Single row configuration facilitates compact PCB layouts.
Product Description
Molex 22-12-2054 KK 254 Series Right Angle Through Hole Pin Header is a reliable electronic component designed for wire-to-board applications. Featuring 5 brass contacts plated with gold, this connector ensures excellent electrical conductivity and durability. The right angle orientation and single row configuration provide efficient PCB mounting and space saving in electronic designs.
The pin header's nylon housing meets UL 94V-0 standards, offering flame resistance and enhanced mechanical stability. Its unshrouded construction allows easy access and mating with compatible connector housings, such as the 2695 Series with lock mechanisms, facilitating secure and stable connections.
Rated for a voltage of 250V and a current capacity of 4A, it is suitable for a wide range of electronic applications including industrial, telecommunications, and consumer electronics. The connector supports operation in temperatures ranging from -40°C to 80°C, making it versatile for use in diverse environmental conditions.
This through hole mount pin header uses solder termination for strong mechanical and electrical bonds to printed circuit boards. The standard 2.54 mm pitch guarantees compatibility with numerous PCB designs and industry-standard components.
Right angle orientation improves board layout flexibility. Gold plating on brass contacts enhances corrosion resistance and conductivity. Nylon housing provides flame retardance and durability. Robust operating voltage and current ratings support demanding electronic circuits.
Unshrouded design eases insertion and connection of mating components. Suitable for industrial, laboratory, and commercial electronic assemblies.
This pin header kit is ideal for designers and manufacturers seeking dependable PCB connectors in control systems, telecommunications equipment, and embedded electronics. Explore our category for more PCB Headers and Molex connectors optimized for your industrial and professional electronic applications.
