Nexperia 1-Element Uni-Directional ESD Protection Diode, 42W, 2-Pin SOD-323 PESD5V0L1UA,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 1.8mm |
| Model | PESD5V0L1UA,115 |
| Width | 1.35mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 12V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 7.2V |
| Maximum Reverse Stand-off Voltage Vwm | 5V |
| Peak Pulse Power Dissipation Pppm | 42W |
| Maximum Peak Pulse Current Ippm | 3.5A |
| Maximum Reverse Leakage Current | 100nA |
Key Features
- Offers peak pulse power dissipation of 42 watts for robust ESD protection.
- Uni-directional diode configuration designed for single signal line protection.
- Minimum breakdown voltage of 7.2 volts with a clamping voltage of 12 volts.
- Operates reliably in temperature ranges from -55°C to 150°C.
- Compact surface-mount SOD-323 package with dimensions 1.8mm length and 1.35mm width.
- Rated for maximum reverse stand-off voltage of 5 volts and peak pulse current of 3.5 amperes.
- Minium reverse leakage current of 100nA ensures minimal signal distortion.
- AEC-Q101 automotive standard compliant for high reliability applications.
Product Description
Nexperia PESD5V0L1UA,115 1-Element Uni-Directional ESD Protection Diode, rated for 42 watts peak pulse power dissipation, is optimized to protect individual signal lines from electrostatic discharge and transient voltage spikes. This diode is housed in a compact 2-pin SOD-323 surface mount package, making it suitable for space-constrained electronic designs.
The device features a minimum breakdown voltage of 7.2 volts, a maximum reverse stand-off voltage of 5 volts, and a clamping voltage of 12 volts, ensuring effective transient voltage suppression and reliable circuit protection. It supports continuous operation in a wide temperature range from -55°C up to 150°C, suitable for demanding industrial, automotive, and consumer electronics environments.
With a low maximum reverse leakage current of 100nA and compliance to the AEC-Q101 automotive standard, this diode guarantees minimal interference with signal integrity while maintaining robust performance in harsh conditions. Its low capacitance attributes reduce parasitic effects, making it ideal for safeguarding sensitive electronic components and PCB traces.
Key features include uni-directional diode configuration, single element per chip, and a compact form factor of 1.8mm length, 1.35mm width, and 1.1mm height, facilitating efficient PCB layout. The peak pulse current rating of 3.5A and a pin count of 2 ease integration into protective circuit designs.
Industries such as automotive electronics, industrial control systems, telecommunications equipment, and consumer electronics benefit from using this diode for enhanced resilience against ESD events and transient surges. It supports compact, surface-mounted designs requiring reliable, high-performance voltage protection.
Set includes one Nexperia PESD5V0L1UA,115 uni-directional ESD Protection Diode in a 2-pin SOD-323 package. For exploring similar semiconductors and diodes, browse the EnvMart Electronics & Electricals Semiconductors category for comprehensive component selections.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Nexperia PESD5V0L1UA,115 has a peak pulse power dissipation of 42 watts, providing robust ESD protection.
This model has a maximum reverse stand-off voltage of 5 volts, ensuring effective voltage protection.
The clamping voltage for this diode is 12 volts, which helps in transient voltage suppression.
It operates reliably in temperature ranges from -55°C to 150°C, suitable for various environments.
The maximum peak pulse current rating is 3.5 amperes, allowing it to handle significant transient events.
The dimensions of the SOD-323 package are 1.8mm in length, 1.35mm in width, and 1.1mm in height.
This diode features a uni-directional configuration, designed specifically for single signal line protection.
Yes, it is compliant with the AEC-Q101 automotive standard, ensuring high reliability in automotive applications.
The minimum breakdown voltage is 7.2 volts, which is crucial for effective protection against overvoltage conditions.
The maximum reverse leakage current is 100nA, which helps minimize signal distortion.
This model supports surface mounting, making it suitable for compact electronic designs.
This diode is a single element per chip, simplifying integration into protective circuit designs.
