| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 0.65mm |
| Length | 1.25mm |
| Model | PESD15VS1UB,115 |
| Width | 0.85mm |
| Mount Type | Surface |
| Series | PESD |
| Maximum Operating Temperature | 150°C |
| Package Type | I-IGIA |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 40V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 17.6V |
| Maximum Reverse Stand-off Voltage Vwm | 15V |
| Peak Pulse Power Dissipation Pppm | 160W |
| Test Current It | 5mA |
| Maximum Peak Pulse Current Ippm | 5A |
| Maximum Reverse Leakage Current | 50nA |
| DiodesZetex D1213A-01T-7 1-Element Uni-Directional TVS Diode, 2-Pin SOD-523Brand | DiodesZetex |
Nexperia PESD15VS1UB,115 is a 1-element uni-directional ESD Protection Diode designed for transient voltage suppression in electronic circuits. Rated at 160 W peak pulse power dissipation, this diode efficiently protects sensitive components from electrostatic discharge and electrical transients.
Featuring a surface mount 2-pin I-IGIA package, the component is compact with dimensions of 1.25 mm in length, 0.85 mm width, and a height of 0.65 mm, enabling versatile placement in dense circuit boards.
This diode has a minimum breakdown voltage of 17.6 V and a maximum reverse stand-off voltage of 15 V, making it suitable for protecting circuits operating within these voltage ranges. It operates reliably under a wide temperature range from -65°C to 150°C and conforms to automotive-grade standards (AEC-Q101), ensuring robustness in automotive and industrial applications.
The device offers a clamping voltage of 40 V and a peak pulse current rating of 5 A, delivering effective suppression against voltage spikes and surges. Its uni-directional diode configuration supports single-line protection in applications such as power connectors, semiconductor circuits, and communication equipment.
This diode provides superior protection against electrostatic discharge events. Its compact form factor supports surface mount technology for efficient board layout. Automotive standard compliance guarantees reliability for vehicle electronics.
Wide operating temperature range suitable for industrial and commercial environments. High peak pulse power dissipation protects against severe voltage transients.
Commonly used in industrial electronics, automotive electronics, communications devices, and power supply modules, this ESD diode protects critical components enhancing system durability and performance.
