Vishay 60 V 35 A Rectifier & Schottky Diode Schottky DPAK V35PW60HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1.4mm |
| Length | 9.4mm |
| Model | V35PW60HM3/I |
| Width | 6.32mm |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | JESD 201 Class 2 whisker test, RoHS and AEC-Q101 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 35A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 5mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 260A |
| Maximum Forward Voltage Vf | 0.72V |
Key Features
- Features trench MOS Schottky technology for efficient switching performance.
- Has a maximum forward voltage of 0.72 V for low power loss operation.
- Supports a peak non-repetitive forward surge current of 260 A.
- Designed for surface mounting in a TO-252 DPAK package.
- Operates reliably within the temperature range of -40°C to 150°C.
- Complies with automotive standard AEC-Q101 and RoHS directives.
- Suitable for low voltage, high frequency DC/DC converters and polarity protection.
- JESD 201 Class 2 whisker test approved ensuring product reliability.
Product Description
Vishay V35PW60HM3/I Rectifier & Schottky Diode is a robust semiconductor device engineered for high efficiency and reliability in electronic power applications. It features trench MOS Schottky technology that delivers a low forward voltage drop of 0.72 V, which minimizes power losses and heat generation.
This diode offers a maximum continuous forward current of 35 A and can handle surge currents up to 260 A, making it suitable for demanding transient conditions. The device operates effectively in a wide temperature range from -40°C to 150°C, ensuring stable performance in harsh environments.
Encapsulated in a compact TO-252 (DPAK) surface-mount package, this rectifier is designed for automated assembly operations with a typical profile height of 1.4 mm. It is ideal for applications such as low voltage, high frequency DC/DC converters, freewheeling diodes, and polarity protections in automotive and industrial electronics.
The V35PW60HM3/I meets the AEC-Q101 automotive standard and the JESD 201 Class 2 whisker test, further assuring reliability in critical applications. Its compact dimensions (9.4 mm length x 6.32 mm width x 1.4 mm height) enable space-efficient circuit designs.
Trench MOS Schottky technology offers low forward voltage and improved efficiency. Maximum continuous forward current of 35 A supports robust power handling. Peak non-repetitive forward surge current rating of 260 A ensures transient tolerance.
Wide operating temperature range from -40°C to 150°C suits extreme environments. Compliant with AEC-Q101 automotive standard and RoHS for quality and sustainability. Compact TO-252 (DPAK) surface-mount package with low profile height aids in automated placement.
JESD 201 Class 2 whisker test passed, enhancing reliability in final assembly. Optimized for use in DC/DC converters, freewheeling, and polarity protection applications. Explore more semiconductor and rectifier solutions to enhance the efficiency and reliability of your industrial, automotive, and electronics manufacturing projects on EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 35 A.
It has a peak non-repetitive forward surge current rating of 260 A.
The maximum forward voltage drop is 0.72 V, which helps in minimizing power loss during operation.
This diode operates reliably within a temperature range of -40°C to 150°C.
It is encapsulated in a TO-252 (DPAK) surface-mount package.
Yes, it complies with the AEC-Q101 automotive standard, ensuring reliability in automotive applications.
The dimensions of this unit are 9.4 mm in length, 6.32 mm in width, and 1.4 mm in height.
It is suitable for low voltage, high frequency DC/DC converters, freewheeling diodes, and polarity protection applications.
The peak reverse repetitive voltage rating is 60 V.
This diode meets the JESD 201 Class 2 whisker test, RoHS directives, and AEC-Q101 standards.
The diode configuration for this model is single.
The peak reverse current rating is 5 mA.
