Nexperia 100 V 215 mA High-Speed Switching Diode, Surface Mount SOT-23 Package BAV99,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 100 V 215 mA High-Speed Switching Diode, Surface Mount SOT-23 Package BAV99,215

Name: Nexperia 100 V 215 mA High-Speed Switching Diode, Surface Mount SOT-23 Package BAV99,215
Brand: Nexperia
SKU: 90052
Price: 0.02 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1mm
Length	3mm
Model	BAV99,215
Width	1.4mm
Mount Type	Surface
Series	BAV99
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Forward Current	215 mA
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	215mA
Peak Reverse Repetitive Voltage Vrrm	100V
Diode Configuration	Series
Rectifier Type	Switching
Peak Reverse Current Ir	500nA
Peak Non-Repetitive Forward Surge Current Ifsm	4A
Maximum Forward Voltage Vf	1.25V
Peak Reverse Recovery Time trr	4ns
NXP Dual Switching Diode, Series, 215mA 100V, 3-Pin SOT-23 BAV99/8,215Brand	NXP

Key Features

Designed for high-speed switching with a reverse recovery time of 4 ns.
Maximum continuous forward current of 215 mA supports robust performance.
Peak reverse repetitive voltage rated at 100 V, suitable for protection circuits.
Low leakage current and low capacitance enhance efficiency and reliability.
Surface mount SOT-23 package ensures compact footprint for PCB designs.
Rated for automotive applications with AEC-Q101 qualification.
Operates within wide temperature range from -65°C to 150°C.
Series diode configuration ideal for reverse polarity protection and signal switching.

Product Description

Nexperia presents the BAV99,215 High-Speed Switching Diode, engineered for demanding electronic circuit applications. With a maximum reverse voltage of 100 V and a continuous forward current of 215 mA, this diode offers reliable performance for signal switching, reverse polarity protection, and fast circuit responses. The device features a compact surface mount SOT-23 package, making it ideal for space-constrained PCB layouts.

Designed for high-speed switching with a reverse recovery time of 4 ns. Maximum continuous forward current of 215 mA supports robust performance. Peak reverse repetitive voltage rated at 100 V, suitable for protection circuits.

Low leakage current and low capacitance enhance efficiency and reliability. Surface mount SOT-23 package ensures compact footprint for PCB designs. Rated for automotive applications with AEC-Q101 qualification. Operates within wide temperature range from -65°C to 150°C.

Series diode configuration ideal for reverse polarity protection and signal switching.

This diode is suitable for use in automotive electronics, industrial signal switching, and general-purpose protection circuits. Its robust electrical parameters make it a preferred choice for manufacturers requiring reliable surface mount components for fast switching operations. The BAV99,215’s SOT-23 package offers ease of assembly in automated production lines, helping to streamline manufacturing and improve board density.

Industrial, automotive, and commercial electronics benefit from the high efficiency, fast response, and low leakage current provided by this device. When integrating this diode, consider its wide operating temperature and automotive standard certifications for use in harsh environments.
