STMicroelectronics High Voltage Diode 600V 20A TO-220 Package STTH16L06CTY
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 3.75mm |
| Brand | STMicroelectronics |
| Height | 15.75mm |
| Length | 10.4mm |
| Model | STTH16L06CTY |
| Width | 4.6mm |
| Mount Type | Through Hole |
| Series | STTH1602C |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-220 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Diode Configuration | Common Cathode |
| Rectifier Type | High Voltage |
| Peak Reverse Current Ir | 240μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 120A |
| Maximum Forward Voltage Vf | 2.08V |
| Peak Reverse Recovery Time trr | 55ns |
Key Features
- Operates reliably at high voltages up to 600V.
- Capable of supporting continuous forward current up to 20A.
- Features a TO-220 package for efficient heat dissipation and easy mounting.
- Common cathode configuration ensures practical integration into circuit designs.
- Forward voltage drops of up to 2.08V for responsive switching.
- Peak surge current handling up to 120A adds durability.
- Offers fast reverse recovery time at 55ns, suitable for switching operations.
- RoHS compliant and meets automotive standard AEC-Q101.
Product Description
STMicroelectronics STTH16L06CTY High Voltage Diode is engineered for advanced rectification and power management tasks within demanding electronic and industrial environments. This Schottky-type diode provides a peak reverse repetitive voltage rating of 600V and supports a continuous forward current of 20A, making it ideal for both high-voltage and high-current applications.
Designed in a TO-220 package, this diode offers superior thermal characteristics that facilitate efficient heat dissipation, ensuring dependable operation during periods of elevated load and temperature. The through-hole mounting configuration simplifies the integration process into various PCB layouts, promoting stability and ease of assembly.
Its common cathode configuration makes it highly suitable for parallel and series circuit connections, aiding in complex power distribution systems. Peak surge current capability of 120A enhances its reliability during transient events, while the low forward voltage drop of 2.08V provides energy-efficient switching performance.
With accelerated reverse recovery time of 55ns, the diode is optimal for high-frequency switching in power supplies, inverters, and industrial controllers. The device is rated for operation from -40°C to 175°C, granting resilience in harsh environments, and it is certified according to RoHS and automotive AEC-Q101 standards for broad use in automotive, industrial, and consumer electronics.
Operates reliably at voltages up to 600V. Supports continuous forward current of 20A. TO-220 package enables robust thermal management. Handles non-repetitive forward surge currents up to 120A. Fast reverse recovery time (55ns) suits high-speed switching tasks.
Automotive-standard compliance expands eligibility for vehicle systems. RoHS compliant for safe and sustainable electronics production. Ideal for rectification, power conversion, inverter, and industrial automation applications.
This diode is a trusted choice for engineers and designers crafting power supplies and rectifying circuits across sectors such as industrial automation, manufacturing, renewable energy, and electronic telecommunications. Explore additional Schottky diodes and rectifiers from STMicroelectronics and browse the full range of discrete semiconductors at EnvMart for your next project.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The STMicroelectronics STTH16L06CTY diode has a peak reverse repetitive voltage rating of 600V, making it suitable for high-voltage applications.
This model supports a continuous forward current of up to 20A, allowing it to handle significant power loads.
The diode is housed in a TO-220 package, which facilitates efficient heat dissipation and easy mounting.
It can handle peak non-repetitive forward surge currents of up to 120A, enhancing its reliability during transient events.
The maximum forward voltage drop for this model is 2.08V, which contributes to its energy-efficient switching performance.
The STTH16L06CTY features a fast reverse recovery time of 55ns, making it suitable for high-frequency switching applications.
It operates reliably within a temperature range of -40°C to 175°C, allowing for use in harsh environments.
This diode has a common cathode configuration, which is beneficial for integrating into parallel and series circuit connections.
It is RoHS compliant and meets the automotive standard AEC-Q101, making it suitable for automotive and industrial applications.
The diode features a through-hole mounting type, which simplifies integration into various PCB layouts.
This diode has a pin count of 3, which is standard for its configuration and application.
It is suitable for rectification, power conversion, inverters, and industrial automation applications due to its high voltage and current ratings.
