Vishay Schottky Diode 60V 30A 8-Pin FPAK V30KM60HM3/H
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1.09mm |
| Length | 6.35mm |
| Model | V30KM60HM3/H |
| Width | 5.3mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 165°C |
| Package Type | FPAK |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 30A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 35mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 240A |
| Maximum Forward Voltage Vf | 0.67V |
Key Features
- Designed with Trench MOS Schottky technology for low forward voltage drop.
- Supports a maximum continuous forward current of 30A for robust power handling.
- Provides a peak reverse repetitive voltage of 60V suitable for low voltage and high frequency circuits.
- Compact FPAK surface-mount package with 8-pin configuration, ideal for PCB integration.
- Meets automotive AEC-Q101 standards for high reliability.
- Wide operating temperature range from -40°C to 165°C for demanding environments.
- RoHS compliant for environmentally friendly designs.
- Peak non-repetitive forward surge current rated at 240A for transient protection.
Product Description
Vishay V30KM60HM3/H Schottky Diode, designed for demanding power rectification applications, offers high efficiency operation with a maximum continuous forward current of 30A and a peak reverse repetitive voltage of 60V. This diode utilizes advanced Trench MOS Schottky (TMBS®) technology to deliver exceptionally low forward voltage drop, minimizing power losses and improving thermal performance - ideal for DC/DC converters, inverters, freewheeling diodes, and polarity protection in automotive, industrial, and commercial systems.
Housed in a compact 8-pin FPAK package, this surface-mount diode streamlines integration, especially into high-density printed circuit board layouts. Its single Schottky configuration ensures reliable rectification and fast switching speeds, while maintaining stable operation across a wide temperature range from -40°C to 165°C, enabling performance in harsh environments.
Trench MOS Schottky design for ultra-low VF (0.34V at IF = 5A) enhances system efficiency. Peak non-repetitive forward surge current capability of 240A offers robust resilience to transient events. Maximum forward voltage drop is just 0.67V, reducing heat generation and improving power management.
The device is compliant with RoHS standards and meets automotive AEC-Q101 for safety and reliability in automotive applications. Pin count of 8 supports versatile circuit integration, suitable for a broad range of surface-mount assemblies.
Applications include low voltage/high frequency inverters, DC/DC converters, freewheeling circuits, polarity protection, and other industrial electronic designs where efficiency and compact footprint are essential. The component’s wide temperature range and automotive standard compliance broaden its use to advanced automotive electronics as well as demanding industrial and commercial environments.
Dimensions are 6.35mm (Length) × 5.3mm (Width) × 1.09mm (Height), facilitating neat PCB integration. Peak reverse current is 35mA, supporting low leakage in reverse bias conditions.
Explore the full range of Vishay Schottky diodes and rectifiers on EnvMart to meet high-efficiency power conversion needs in automotive, industrial, and commercial projects.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current is 30A, allowing for robust power handling in various applications.
The peak reverse repetitive voltage is rated at 60V, making it suitable for low voltage and high frequency circuits.
This model operates within a temperature range of -40°C to 165°C, accommodating demanding environments.
It is housed in a compact 8-pin FPAK surface-mount package, facilitating easy integration into printed circuit boards.
The maximum forward voltage drop is 0.67V, which helps in reducing heat generation during operation.
The diode has a peak non-repetitive forward surge current rating of 240A, providing resilience to transient events.
Yes, it meets RoHS standards and is compliant with automotive AEC-Q101 for high reliability in automotive applications.
The peak reverse current is rated at 35mA, which supports low leakage in reverse bias conditions.
This diode is suitable for applications such as DC/DC converters, inverters, freewheeling circuits, and polarity protection.
The dimensions are 6.35mm in length, 5.3mm in width, and 1.09mm in height, facilitating neat PCB integration.
It features a single Schottky configuration, ensuring reliable rectification and fast switching speeds.
It utilizes Trench MOS Schottky technology, which provides a low forward voltage drop and enhances system efficiency.
