Microchip 16 bit Digital Signal Processor 40 MIPS 128kB FLASH 64-Pin TQFP dsPIC33FJ128GP306A-I/PT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.05mm |
| Length | 10mm |
| Model | dsPIC33FJ128GP306A-I/PT |
| Width | 10mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 85°C |
| Package Type | TQFP |
| Minimum Operating Temperature | -40°C |
| Ram size | 16kB |
| ADC Resolution | 12bit |
| Timer Resolution | 16bit |
| Pin Count | 64 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 3.6V |
| Minimum Supply Voltage | 3V |
| Program Memory Size | 128kB |
| Number of Timers | 9 |
| Instruction Set Architecture | RISC |
| Program Memory Type | FLASH |
| Number of ADCs | 1 |
| Device Million Instructions per Second | 40MIPS |
| Number of PWM Units | 1 |
| PWM Resolution | 16bit |
| ADC Channels | 18 |
| Number of PWM Channels | 8 |
| Microchip, 16bit Digital Signal Processor 40MHz 128 kB Flash 64-Pin TQFPBrand | Microchip |
Key Features
- This DSP operates at a maximum clock frequency of 40 MIPS.
- Features a 16-bit data bus width with a 128kB FLASH program memory.
- Includes 16kB RAM and supports RISC instruction set architecture.
- Operates with a voltage range of 3V minimum to 3.6V maximum.
- Equipped with 18 ADC channels offering 12-bit resolution.
- Contains 1 ADC unit and 8 PWM channels with 16-bit resolution.
- Suitable for surface mount applications with a compact 10mm x 10mm footprint and 1.05mm height.
- Operates reliably from -40°C to 85°C supporting automotive standard AEC-Q100.
Product Description
Microchip dsPIC33FJ128GP306A-I/PT is a high-performance 16 bit Digital Signal Processor delivering up to 40 MIPS (Million Instructions Per Second). The device comes with 128kB of FLASH program memory and 16kB RAM, implementing a RISC architecture optimized for digital signal control tasks.
This DSP is designed to execute digital filter algorithms, high-speed precision digital control loops, and audio/speech processing efficient for industrial and automotive applications. It is packaged in a durable 64-Pin TQFP suitable for surface mount technology and compact designs.
The device operates over a power supply voltage range from 3V up to 3.6V, and a wide temperature span from -40°C to 85°C, making it compatible with automotive standard AEC-Q100, ensuring robustness in harsh environments. The 18 ADC channels have 12-bit resolution, supporting precise analog-to-digital conversions.
Equipped with 8 PWM channels and 9 timers with 16-bit resolution, this processor is ideal for motor control and power management applications. Its small 10mm by 10mm by 1.05mm form factor allows integration in compact systems requiring high digital signal processing capabilities.
Maximum clock frequency: 40 MIPS for fast processing. 16-bit data bus width with RISC architecture. 128kB FLASH memory and 16kB RAM for complex programs. Wide operating voltage range from 3V to 3.6V. Automotive AEC-Q100 certified for reliable operation.
Advanced peripherals including ADC, PWM channels, and timers. Compact 64-Pin TQFP package suitable for surface mount designs.
This Digital Signal Processor is widely used in industrial, automotive, embedded systems, motor control, power conversion, and signal processing applications. It combines efficient code execution with versatile peripherals for creating high-performance, energy-efficient embedded solutions.
Explore our extensive Microchip DSP range and other semiconductor components at EnvMart for your electronic design and manufacturing requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum clock frequency of this model is 40 MIPS (Million Instructions Per Second).
It operates with a voltage range from 3V minimum to 3.6V maximum.
This processor features 18 ADC channels, each offering 12-bit resolution.
It has a program memory size of 128kB.
The processor is packaged in a 64-Pin TQFP suitable for surface mount applications.
It operates reliably within a temperature range of -40°C to 85°C.
This model includes 8 PWM channels, each with 16-bit resolution.
The device has a height of 1.05mm and a footprint of 10mm x 10mm.
It complies with the automotive standard AEC-Q100, ensuring reliability in automotive applications.
This DSP is equipped with 9 timers, each providing 16-bit resolution.
It implements a RISC instruction set architecture, optimized for digital signal control tasks.
The processor includes 16kB of RAM for program execution and data storage.
