Microchip 16 bit Digital Signal Processor 40 MIPS 12kB FLASH 28-Pin SPDIP DSPIC33FJ128GP708-I/PT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.05mm |
| Length | 12mm |
| Model | DSPIC33FJ128GP708-I/PT |
| Width | 7.49mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 85°C |
| Package Type | SPDIP |
| Minimum Operating Temperature | -40°C |
| Ram size | 1kB |
| ADC Resolution | 12bit |
| Timer Resolution | 16bit |
| Pin Count | 28 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 3.6V |
| Minimum Supply Voltage | 3V |
| Program Memory Size | 12kB |
| Number of Timers | 3 |
| Instruction Set Architecture | RISC |
| Program Memory Type | FLASH |
| Number of ADCs | 2 |
| Device Million Instructions per Second | 40MIPS |
| Number of PWM Units | 4 |
| PWM Resolution | 16bit |
| ADC Channels | 24 |
| Number of PWM Channels | 6 |
Key Features
- Operates with a 3V to 3.6V supply voltage range suitable for low power applications.
- Features a RISC instruction set architecture with 1kB RAM and 12kB FLASH program memory.
- Includes 2 ADCs with 24 ADC channels and 12-bit resolution for precise analog data conversion.
- Equipped with 6 PWM channels across 4 PWM units and 3 timers with 16-bit timer resolution.
- Operating temperature range from -40°C to 85°C enabling use in diverse environments.
- Automotive grade AEC-Q100 compliant for reliable automotive applications.
- Contains enhanced CAN (ECAN) module and communication interfaces such as SPI, I2C, and UART.
- Supports a 16-bit data bus width and a modified Harvard CPU architecture optimized for DSP workloads.
Product Description
Microchip DSPIC33FJ128GP708-I/PT is a high-performance 16-bit Digital Signal Processor designed for embedded applications that require efficient digital signal control. This model offers a maximum CPU clock speed of 40 MIPS and is based on a modified Harvard architecture with optimized RISC instruction set, delivering DSP-like functionality with the ease of MCU operation.
The device operates at a supply voltage between 3V and 3.6V and features 12kB of FLASH program memory and 1kB RAM to support complex algorithms. It comes in a 28-Pin SPDIP package with compact physical dimensions (12 mm length, 7.49 mm width, 1.05 mm height) suitable for space-constrained designs.
This Digital Signal Processor includes multiple peripheral features for versatile application integration, such as two 12-bit ADCs with 24 channels for high-accuracy analog-to-digital conversions, six PWM channels among four PWM units for motor and power control, and three 16-bit timers enhancing timing accuracy. The presence of communication modules including SPI, I2C, UART, and an enhanced CAN (ECAN) controller makes it ideal for industrial, automotive, and embedded control applications.
The operating temperature range from -40°C to 85°C and compliance with the AEC-Q100 automotive standard ensures robust performance in harsh operating environments. With 16-bit timer resolution, two 40-bit accumulators supporting saturation and rounding, and extensive addressing capabilities up to 4 million instruction words, this processor streamlines complex signal processing and control tasks.
This DSP is widely used in industrial manufacturing control systems, automotive embedded control units, power management systems, and other applications requiring precise DSP functionalities in compact form factors.
Operates between 3V and 3.6V supply voltages providing low power consumption. Delivers maximum CPU speed of 40 MIPS for real-time processing. Includes multiple communication interfaces for flexible system integration. Equipped with automotive-grade qualifications for reliability.
Compact SPDIP packaging ensures easy incorporation into varied hardware designs. Explore the full range of Microchip DSP products for diverse digital signal processing needs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a maximum CPU clock speed of 40 MIPS, allowing for efficient real-time processing of digital signals.
It operates with a supply voltage range of 3V to 3.6V, making it suitable for low power applications.
It features 12kB of FLASH program memory to support complex algorithms and applications.
This unit comes in a 28-Pin SPDIP package, which is compact and suitable for space-constrained designs.
It supports six PWM channels across four PWM units, enabling effective motor and power control.
This model includes communication interfaces such as SPI, I2C, UART, and an enhanced CAN (ECAN) module for flexible system integration.
It utilizes a RISC instruction set architecture, optimized for DSP workloads.
The dimensions of this model are 1.05mm in height, 12mm in length, and 7.49mm in width.
It is compliant with the AEC-Q100 automotive standard, ensuring reliability for automotive applications.
