Maxim Integrated Audio Codec IC 3-Channel 24-Pin TQFN MAX9860ETG+
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 16 bit |
| Brand | Maxim Integrated |
| Height | 0.75mm |
| Length | 4.1mm |
| Model | MAX9860ETG+ |
| Mount Type | Surface |
| Sampling rate | 48kHz |
| Series | MAX9860 |
| Maximum Operating Temperature | 85°C |
| Package Type | TQFN |
| Sub Type | Audio Codec IC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 3 |
| Pin Count | 24 |
| Maximum Supply Voltage | 1.9V |
| Minimum Supply Voltage | 1.8V |
| Number of DACs | 1 |
| Number of ADCs | 2 |
Key Features
- Operates on a single supply voltage between 1.8V and 1.9V for efficient power usage.
- Features a 16-bit resolution with 48kHz maximum sampling rate for high-quality audio.
- Includes one DAC and two ADCs supporting flexible audio signal conversion.
- Supports digital highpass elliptical filters with 217Hz notch for GSM noise reduction.
- Offers automatic microphone gain control and noise gate for clean audio input.
- Low-noise dual microphone inputs enhance sound clarity.
- Provides a mono 30mW BTL headphone amplifier for direct audio output.
- Compatible with master clock frequencies from 10MHz to 60MHz and sample rates from 8kHz to 48kHz.
Product Description
Maxim Integrated MAX9860ETG+ Audio Codec IC is a compact, 3-channel audio codec solution featuring a 24-pin thin QFN package measuring 4.1mm in length and 0.75mm in height. Designed for surface mount applications, it integrates one digital-to-analog converter (DAC) and two analog-to-digital converters (ADCs) supporting 16-bit resolution at sampling rates up to 48kHz.
This device operates with a single power supply voltage ranging from 1.8V to 1.9V, ensuring power-efficient performance suitable for portable and mobile audio devices. Its digital highpass elliptical filter with a 217Hz notch effectively eliminates GSM interference noise, enhancing audio quality.
Equipped with dual low-noise microphone inputs and automatic microphone gain control with noise gate functionality, the MAX9860ETG+ guarantees clear audio capture in noisy environments. The integrated mono 30mW bridge-tied load (BTL) headphone amplifier allows direct connection to headphones, useful in audio accessories and communication devices.
Compatible with master clock frequencies from 10MHz to 60MHz and supporting sample rates from 8kHz to 48kHz, it offers flexible digital audio interface options. The device utilizes a 2-wire I²C-compatible control interface, enabling easy control and configuration.
The MAX9860ETG+ is designed to operate reliably within a wide temperature range of -40°C to 85°C, making it suitable for a variety of environmental conditions. Its 24-pin TQFN package enables compact PCB design, suitable for audio accessories, headsets, mobile phones, portable navigation devices, smartphones, and VoIP phones.
Operates from a 1.8V single supply for power efficiency. Includes digital highpass elliptical filters with GSM notch. Features automatic microphone gain control and noise gate. Provides 30mW mono BTL headphone amplification.
Dual low-noise microphone inputs for high audio clarity. Supports master clock from 10MHz to 60MHz and sampling rates from 8kHz to 48kHz. Configurable via I²C-compatible 2-wire control interface. Compact 24-pin thin QFN package measuring 4.1mm x 0.75mm.
Suitable for industrial, mobile, and communications audio devices. Explore more audio encoder and decoder solutions in the Semiconductor category at EnvMart.
Explore more products in our Audio & Video Encoders & Decoders category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MAX9860ETG+ supports a maximum sampling rate of 48kHz.
It operates on a single supply voltage ranging from 1.8V to 1.9V.
This model supports 3 channels, consisting of one DAC and two ADCs.
The device has a length of 4.1mm and a height of 0.75mm, packaged in a 24-pin TQFN format.
It utilizes a 2-wire I²C-compatible control interface for configuration and control.
The codec provides a resolution of 16 bits for audio signal processing.
It operates reliably within a temperature range of -40°C to 85°C.
Yes, it features digital highpass elliptical filters with a 217Hz notch for GSM noise reduction.
The integrated mono headphone amplifier provides an output of 30mW in BTL configuration.
It is suitable for use in audio accessories, headsets, mobile phones, portable navigation devices, smartphones, and VoIP phones.
This audio codec integrates one DAC and two ADCs.
The MAX9860ETG+ supports master clock frequencies from 10MHz to 60MHz.
