Maxim Integrated CMOS Logic Multiplexer, 3 Elements Triple SPDT, 16-Pin TSSOP MAX4619CUE+
Specifications
| Country of Origin | India |
|---|---|
| Brand | Maxim Integrated |
| Height | 40μm |
| Length | 5.1mm |
| Model | MAX4619CUE+ |
| Width | 4.5mm |
| Mount Type | Surface |
| Output type | CMOS/TTL |
| Series | MAX4619 |
| Configuration | Triple SPDT |
| Maximum Operating Temperature | 70°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | 0°C |
| Pin Count | 16 |
| Number of Elements per Chip | 3 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS |
| Minimum Supply Voltage | 2V |
| Multiplexer/Demultiplexer | Multiplexer |
| Maximum On State Resistance | 100Ω |
| Guaranteed Low Off-Leakage Current | 1nA at +25°C |
Key Features
- Operates with a single supply voltage from 2V to 5.5V.
- Compatible with TTL/CMOS logic levels with input thresholds between 0.8V and 2.4V.
- Maximum on-state resistance of 100 ohms, ensuring low signal degradation.
- High-speed switching with 15ns turn-on and 10ns turn-off times.
- Low off-leakage current of 1nA at 25°C and low on-leakage current of 1nA at 25°C.
- Maintains low crosstalk below -96dB and high off-isolation better than -93dB.
- Low signal distortion less than 0.017% at 600 ohms load.
- Surface mount design in TSSOP package measuring 5.1mm by 4.5mm and 40μm height.
Product Description
The Maxim Integrated MAX4619CUE+ is a high-performance CMOS analog multiplexer integrating three single-pole/double-throw (SPDT) switches within a compact 16-pin TSSOP surface-mount package. Designed for versatile signal routing, this device supports single supply voltages from 2V to 5.5V, enabling broad application in low-voltage systems.
Each switch can handle rail-to-rail analog signals with guaranteed low on-resistance - maximum 100 ohms at specified conditions - providing minimal signal attenuation and distortion. Fast switching times of 15 nanoseconds for turn-on and 10 nanoseconds for turn-off enable high-speed data acquisition and communication applications.
Its CMOS/TTL logic input compatibility with threshold levels from 0.8V to 2.4V ensures seamless integration with common digital logic families. The device exhibits extremely low leakage currents (1nA typical at 25°C) both in the off and on states, maintaining signal integrity and reducing power consumption in battery-powered applications.
Additional performance highlights include minimized crosstalk below -96dB, high off-isolation exceeding -93dB, and low distortion less than 0.017% when driving 600 ohm loads, making it ideal for sensitive analog and audio/video signal routing.
The package dimensions measure 5.1mm length by 4.5mm width and 40 microns height, facilitating compact PCB designs. The device operates reliably within ambient temperatures from 0°C to 70°C.
Applications encompass audio/video signal routing, battery-powered systems, communication equipment, low-voltage data acquisition, and other industrial and commercial electronic systems requiring high-speed, low-voltage multiplexing solutions.
Operates with single supply voltage from 2V to 5.5V. Three SPDT analog switches per chip in CMOS technology. TTL/CMOS input logic thresholds compatible with 5V systems. Maximum on resistance of 100 ohms, ensuring high signal quality.
Low off and on leakage currents minimizing power loss. Fast switching performance (tON 15ns, tOFF 10ns). Low crosstalk and high off-isolation for signal integrity. Compact 16-pin TSSOP surface mount package for dense PCB layouts.
Temperature operating range from 0°C to 70°C. Explore the full range of Maxim Integrated multiplexers and demultiplexer ICs offered by EnvMart to enhance your electronic design projects.
Explore more products in our Semiconductor category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a single supply voltage ranging from 2V to 5.5V.
The maximum on-state resistance is 100 ohms, ensuring minimal signal degradation.
It features fast switching times of 15 nanoseconds for turn-on and 10 nanoseconds for turn-off.
It is compatible with TTL/CMOS logic levels, with input thresholds between 0.8V and 2.4V.
The package measures 5.1mm in length, 4.5mm in width, and has a height of 40μm.
The device operates reliably within an ambient temperature range of 0°C to 70°C.
The guaranteed low off-leakage current is 1nA at 25°C, minimizing power loss.
This model integrates three single-pole/double-throw (SPDT) switches per chip.
It maintains low crosstalk below -96dB, ensuring signal integrity.
This model features a surface mount design, suitable for compact PCB layouts.
The output type is compatible with CMOS and TTL logic families.
